Specifications
Type
Condenser
Polar Pattern
Cardioid
Frequency Response
20 to 20,000 Hz
Output Impendance
70 Ω +/-5
Sensitivity (at 1 kHz, open circuit voltage)
- 36 dBV / Pa(16mV)
Self-Noise
11 dBA
Signal-to-Noise Ratio
83 dB
Maximum SPL, No Pad (1 kHz at 1% THD)
1000 Ω load
137 dB SPL
2500 Ω load
140 dB SPL
5000 Ω load
140 dB SPL
137 dB SPL
2500 Ω load
140 dB SPL
5000 Ω load
140 dB SPL
Maximum SPL, With 15 dB Pad (1 kHz at 1% THD)
1000 Ω load
152 dB SPL
2500 Ω load
155 dB SPL
5000 Ω load
155 dB SPL
152 dB SPL
2500 Ω load
155 dB SPL
5000 Ω load
155 dB SPL
Polarity
Positive pressure on diaphragm produces positive voltage on pin 2 with respect to pin 3
Connector
Three-pin professional audio (XLR), male, balanced
Net Weight
265 g (9.17 oz.)
Housing
Machined, anodized aluminum alloy
Power Requirements
48 V DC phantom power (5.4 mA), IEC standard 61938, P48
