Specifications
Type
Condenser
Polar Pattern
Selectable: Cardioid, Omnidirectional, Bidirectional
Frequency Response
20 to 20,000 Hz
Output Impendance
47 Ω +/-5
Sensitivity (at 1 kHz, open circuit voltage)
Cardioid -30 dBV/Pa
Omnidirectional -35 dBV/Pa
Bidirectional -35 dBV/Pa
Omnidirectional -35 dBV/Pa
Bidirectional -35 dBV/Pa
Self-Noise
Cardioid 5 dBA
Omnidirectional 7 dBA
Bidirectional 8 dBA
Omnidirectional 7 dBA
Bidirectional 8 dBA
Signal-to-Noise Ratio
Cardioid 89 dB
Omnidirectional 87 dB
Bidirectional 86 dB
Omnidirectional 87 dB
Bidirectional 86 dB
Maximum SPL, No Pad (1 kHz at 1% THD)
1000 Ω load
130 dB SPL
2500 Ω load
135 dB SPL
5000 Ω load
135 dB SPL
130 dB SPL
2500 Ω load
135 dB SPL
5000 Ω load
135 dB SPL
Maximum SPL, With 15 dB Pad (1 kHz at 1% THD)
1000 Ω load
145 dB SPL
2500 Ω load
150 dB SPL
5000 Ω load
150 dB SPL
145 dB SPL
2500 Ω load
150 dB SPL
5000 Ω load
150 dB SPL
Polarity
Positive pressure on diaphragm produces positive voltage on pin 2 with respect to pin 3
Connector
Three-pin professional audio (XLR), male
Net Weight
295 g
Housing
Machined, anodized aluminum alloy
Power Requirements
48 V DC phantom power (5.9 mA), IEC 61938, P48
