Specifications
Weight
Weight Net
0.207 kg (0.475 lbs)
Electrical
Sensitivity (at 1kHz, Open Circuit voltage)
−52.5 dBV/Pa (2 mV) 1 Pascal=94 dB SPL
Maximum SPL (1 Khz at 1% THD, 1k ohmsload)
140.5 dB
Clipping Level (1 Khz at 0.25% THD, 1k Ohms load)
−6 dBV (0.5 V)
Power Requirements
11 to 52 Vdc phantom (1.2 mA)
Audio
Polar Pattern
Supercardioid
Frequency Response
50 Hz - 20 kHz
Output Impedance
150 ohms
Signal-to-Noise Ratio (referenced at 94 Db SPL at 1 kHz)
70.5 dB
Dynamic Range (at 1 Khz, 1 K Ohms load)
117 dB
Self Noise (typical, Equivalent SPL, A-weighted)
23.5 dB typical
Connectivity
Connector
Three-pin professional audio (XLR), male
General
Transducer Type
Condenser
