Specifications
Dimensions
Dimensions (HxWxD)
3.4x2.6x0.9"
Electrical
Battery Life @10mW
8-9 hours (depends on battery used)
Max Input Level 1kHz at 1% THD
8.5dBV (7.5Vpp) pad off; 20.5dBV (30Vpp) pad on
Audio
Audio Frequency Response
20 - 20kHz (+/-1dB)
Impedance
1MΩ
Connectivity
Connector
4-pin male mini connector (TA4M)
Construction
Housing
cast aluminum
Shipping
Weight
5 oz (without batteries)
General
Mic Offset Range
0 to 21dB (in 3 dB steps)
Preamp EIN
system gain setting ≥ +20-120 dBV, A-weighted, typical
Occupied Bandwidth
<200kHz
Modulation Type
Shure proprietary digital
Power
Battery Type
AA batteries 1.5 V or Shure SB900B rechargeable Li-Ion
Power
1mW, 10mW, 20mW
Cable
Configuration
unbalanced
RF
Antenna Type
1/4 wave
