Specifications
Dimensions
Height
17.23 in / 437.6 mm
Width/Diameter
14.82 in / 376.4 mm
Carton Height
19.5 in / 495.3 mm
Carton Length
18 in / 457.2 mm
Carton Width
18 in / 457.2 mm
Enclosure Volume
1288.3 cu in / 21111.45 cu cm
Weight
Shipping Weight
30.2 lbs / 13.7 kg
Electrical
Minimum Impedance (Ω Ohms)
5.1Ω
Nominal Impedance (Ω Ohms)
4Ω
Audio
Crossover Frequency
100.0 Hz
Sensitivity Db @ 1W/1M
83 dB
Sensitivity Db @ 2.83V/1M
86 dB
Connectivity
Source Inputs
4 Pin 5.08mm Euroblock
Construction
Color
Black
Certifications
CE, RoHS, UL1480A, UL2239
Identifiers
UPC
752830445086
General
Manufacturer
SoundTube
Manufacturer's Category
RSi Original Pendant
Enclosure Properties
ABS Glass Fiber Reinforced, Injection Molded, Ported
Frequency Response (± 10 dB)
38 Hz - 450 Hz
Frequency Response (± 3 dB)
53 Hz - 175 Hz
Grille Properties
Powder-Coated, Steel
Low Frequency Voice Coil
1.38 in / 35 mm
Low Pass Crossover
6dB per octave 1st order
Max. Continuous Power RMS
150W
Max. Program Power
300W
Subwoofer Driver
10" Polypropylene Cone w/ Butyl Rubber Surround
Tap Selector
Rotary Switch
Transformer Options
25 / 70.7 / 100 V, 8 Ohm direct
Transformer Taps Max. Setting (25V/70.7V/100V)
19W/150W/150W
