Specifications
Dimensions
Height
10.4 in / 264.2 mm
Width/Diameter
10.08 in / 256 mm
Carton Height
13.25 in / 336.55 mm
Carton Length
12 in / 304.8 mm
Carton Width
12 in / 304.8 mm
Weight
Shipping Weight
9.5 lbs / 4.31 kg
Electrical
Minimum Impedance (Ω Ohms)
16 Ω
Nominal Impedance (Ω Ohms)
16 Ω
Audio
Crossover Frequency
3.0 kHz
Sensitivity Db @ 1W/1M
91.2 dB
Sensitivity Db @ 2.83V/1M
88.2 dB
Connectivity
Source Inputs
4 Pin Ceramic Terminal
Network Type: High Pass
6 dB per octave 1st order
Construction
Certifications
CE, EN54, RoHS, UL1480A
General
Manufacturer
SoundTube
Manufacturer's Category
RS-EZ Economical Pendant
Enclosure Properties
Ported, Reinforced ABS
Directivity Factor (Q) (Averaged 100Hz - 10kHz, @ 2kHz)
3.6 and 7.1
Directivity Index (DI) Db (Averaged 100Hz - 10kHz, @ 2kHz)
5.5dB and 8.5dB
Frequency Response (± 10 dB)
80 Hz - 22 kHz
Frequency Response (± 3 dB)
100 Hz - 22 kHz
Grille Properties
Aluminum, Powder-Coated
Low Frequency Voice Coil
1 in / 25.4 mm
Low Pass Crossover
6 dB per octave 1st order
Max. Continuous Power RMS
32W
Max. Program Power
64 W
Tweeter Driver
1" Silk Dome w/ BroadBeam Ring®
Woofer Driver
6.5" Polypropylene Cone w/ Butyl Rubber Surround
Tap Selector
Rotary Switch
Transformer Options
25 / 70.7 / 100 V, 16 Ohm direct
Transformer Taps (25V/70.0V/100V)
4W/32W/32W
