Specifications
Dimensions
Height
18.78 in / 477 mm
Width/Diameter
11.65 in / 295.9 mm
Carton Height
16 in / 406.4 mm
Carton Length
21.5 in / 546.1 mm
Carton Width
14.5 in / 368.3 mm
Enclosure Volume
1008 cu in / 16518.16 cu cm
Mounting Depth
15.37 in / 390.4 mm
Weight
Shipping Weight
24.5 lbs / 11.11 kg
Electrical
Minimum Impedance (Ω Ohms)
8 Ω
Nominal Impedance (Ω Ohms)
8 Ω
Audio
Crossover Frequency
2.5 kHz
Sensitivity Db @ 1W/1M
92 dB
Sensitivity Db @ 2.83V/1M
92 dB
Connectivity
Source Inputs
4 Pin 5.08mm Euroblock
Network Type: High Pass
12 dB per octave 2nd order
Construction
Certifications
CCC, CE, IP44, RoHS, UL1480
General
Manufacturer's Category
SMi Surface Mount
Enclosure Properties
ABS Glass Fiber Reinforced, Injection Molded, Ported
Directivity Factor (Q) (Averaged 100Hz - 10kHz, @ 2kHz)
5.4 and 7.2
Directivity Index (DI) Db (Averaged 100Hz - 10kHz, @ 2kHz)
6.7 dB and 9.4 dB
Frequency Response (± 10 dB)
80 Hz - 22 kHz
Frequency Response (± 3 dB)
105 Hz - 22 kHz
Grille Properties
Powder-Coated, Weatherproof, Stainless Steel
Low Frequency Voice Coil
1.34 in / 34 mm
Low Pass Crossover
12 dB per octave 2nd order
Max. Continuous Power RMS
150 W
Max. Program Power
300 W
Tweeter Driver
1.38" Titanium Compression Driver w/ Waveguide
Woofer Driver
8" High-Efficiency Woofer
Tap Selector
Rotary Switch
Transformer Options
25 / 70.7 / 100 V, 8 Ohm direct
Transformer Taps (25V/70.0V/100V)
19W/150W/150W
