Specifications
Dimensions
Dimensions (HxWxD)
1.7x8.4x10.7 inches
Electrical
THD+N
<.1% @ Full Power
Input Impedance (Balanced/UnbalanceD)
7.2K Ohms/3.6K Ohms
Current Draw - Standby, 1/8 Power
12W/65W (Varies by model)
Audio
Output Power
100W x 2 @ 4/8 Ohms
Frequency Response
100 Hz - 20kHz
Signal-to-Noise Ratio
>100dB
Output Connectors
5mm Euroblock
Connectivity
Input Sensivity
1V (0 dBV)
Input Connectors
3.5mm Euroblock and RCA
Optional Network Input
Dante™
Construction
Amplifier Class
D
Construction
Aluminum Chassis
Mounting
Rack-Mountable
Controls
LED Indicators
Power, Standby, Signal, and Clip
Shipping
Weight
4.5lbs max (varies by model)
General
Remote Volume
0-10VDC
External Mute
Contact-Closure
Controls
USB for programming, Remote Volume, Trim Knobs
Cooling
Convection–Cooling (No Fans)
Power
Power Supply Input
110/240 VAC 50/60Hz (Universal Input)
