Specifications
Dimensions
Dimensions (HxWxD), Excluding Rack Mounts
1.7x8.3x10.7 inches (44x213x272mm)
Electrical
THD + N
<0.05% @ 6dB below clipping
Input Impedance (Balanced/Single-ended/Phantom)
7.2kΩ/3.6kΩ/2.4kΩ
Audio
Frequency Response (+0, -3dB)
20Hz – 20kHz 4/8 Ω, 100Hz – 20kHz 70.7V/100V
Signal to Noise Ratio
>95dB
Input Sensitivity (local inputs)
1V (0dBV)
Dante™Audio Sampling Rates
44.1, 48, 88.2, 96, 176.4, 192 ksps
Dante™/AES67 Network Audio (optional) and Control Port
RJ-45
Output Connectors
5mm Euroblock
1/8 Rated Audio Power
60W/20W
Connectivity
Max. Output Power (all Channels driven)
80/40WRMS x 4 @ 4/8Ω
Input Connectors
3.5mm Euroblock; 24V Phantom Power on 2 channels
Construction
Amplifier Class
D
Construction
Aluminum Chassis
Mounting
Single and Dual Rack Mount (optional)
Controls
LED Indicators
Power
Shipping
Weight
3.4 lbs. (1.6 kg)
General
Channel-to-Channel Isolation (Crosstalk)
>60dB FLX-E-80-4, >85dB FLX-E-160-2
Remote Volume Control
0-10VDC
Control and Status
RVC, RS-232 and Ethernet
Idle
12W/12W
Cooling
Convection (no fan)
Power
Power Supply Input
100-240VAC 50/60Hz (PFC Universal Input)
