Specifications
Dimensions
Capsule Diameter
7.0 mm
Length
15.8 mm
Cable Length
1.2 m
Weight
Weight With Cable And Connector
13 g
Electrical
Power Supply
Direct current
Supply Voltage
2 V to 10 V
Max Power Consumption
0.5 mA
Open Circuit Voltage
40 mV/Pa (-28 dBV) ±2.5 dB
Connector
Mini-XLR, 4-pin, female
Audio
Transducer Type
Condenser (electret)
Operating Principle
Pressure
Polar Pattern
Omnidirectional
Frequency Response
20 - 20,000 Hz
Max SPL At 1 kHz
126 dB SPL
Signal-to-Noise Ratio
51 dB [CCIR; Q-Peak]
Equivalent SPL
32 dB [A, RMS]
