• 50735_TOA-BA-260-CU-Background-Music-Power-Amplifier-60W-Line-Input_ALT01sqr
  • 50735_TOA-BA-260-CU-Background-Music-Power-Amplifier-60W-Line-Input_ALT02sqr
1 2

TOA BA-260 CU Background Music Power Amplifier 60W Line Input

TOA BA-260 CU Background Music Power Amplifier 60W Line Input

SoundPro Item: 50735 | Part Number: BA-260 CU

$523.00
$645.00 $523.00
Your Price Sold out
MSRP: $645.00 | MAP: $523.00

Usually ships in 5-7 business days

  • Single-Source BGM Design Simplifies Deployment In Commercial Installed Audio
  • Remote Master Volume Control Enables Convenient Level Adjustment From A Distance
  • Thermal Protection Circuits Prevent Damage During Overheating Events
  • Accessory Security Knobs Restrict Unauthorized Volume Changes In Public Venues
  • Multiple Speaker Output Configurations Support 4-Ohm, 25V, And 70V Distributed Systems
  • UL/cUL Listed For Compliance With Common Commercial Installation Requirements
  • Compatible With Optional BG-Series Mixer Amplifiers For 2-Channel Broadcast Capability
Log in or register for YOUR best price

The TOA BA-260 CU is a 60W power amplifier built for installed background music and general announcement applications in commercial environments such as retail stores, bars, and banquet rooms. It accepts a single audio source via RCA pin jack or removable terminal block line input, making it straightforward to deploy in spaces that do not require paging or music-on-hold functionality. Multiple speaker output configurations, including 4-ohm, 25V, and 70V distributed audio, give integrators flexibility when matching existing speaker infrastructure.

For AV integrators specifying permanent installs, the BA-260 CU addresses common field concerns directly. Thermal protection circuits shut the unit down before damage occurs, extending system life in enclosed equipment spaces. Accessory security knobs prevent unauthorized volume adjustments, a practical necessity in public-facing venues. Bass and treble tone controls allow on-site tuning without additional signal processing. When paired with the optional BG-220 or BG-235 mixer amplifiers, the system supports 2-channel broadcast, expanding coverage without a separate zone controller. Rack mounting is supported via optional brackets, and UL/cUL listing satisfies common installation compliance requirements.

Downloads

View full details

Specifications

Certifications
Listing
UL/cUL
Dimensions
Width
210 mm (8.27")
Height
94.3 mm (3.71")
Depth
265 mm (10.43")
Weight
Unit Weight
4.6 kg (10.14 lbs)
Electrical
Power Source
120 V AC, 60 Hz
Rated Output
60 W
Power Consumption
130 W (rated output), 66 W (based on cULus standards)
Audio
Frequency Response
50 Hz - 20 kHz
Total Harmonic Distortion
0.5% or less, at 1 kHz, rated output
Signal To Noise Ratio
80 dB or more (Band Pass: 20 Hz - 20 kHz, Tone Controls: Centered)
Output Regulation
2 dB or less, no load to full load (1 kHz)
Tone Control
Bass: +/-10 dB at 100 Hz, Treble: +/-10 dB at 10 kHz
Connectivity
Input
Line In: 0 dB/+4 dB (selectable), 10 kOhm, unbalanced, removable terminal block or RCA jack
Speaker Output
4 Ohm, 25 V (10 Ohm) and 70 V (83 Ohm), balanced, removable terminal block
Bridge Output
Parallel in Line In, removable terminal block
Controls
Controls
Master gain control, Bass tone control, Treble tone control, Input Level selector switch, Remote Volume control, Power ON/OFF switch
Indicators
Power LED, Signal LED, Peak LED
Construction
Panel Finish
ABS resin, black
Case Finish
Steel plate, black, paint
Environmental
Operating Temperature
0 C to +35 C (32 F to 95 F)
Operating Humidity
35% to 80% RH (no condensation)
Included Items
Volume Control Cover
YA-920 x1
Removable Terminal Plug (2 pins)
x3
Removable Terminal Plug (4 pins)
x1
Optional Accessories
Rack Mounting Bracket
MB-25B-BK, MB-25B-J
