• TOA BG-2035 35-Watt 5 Input Mixer Amplifier
1 1

TOA BG-2035 35W 5-Input Mixer Amplifier

TOA BG-2035 35W 5-Input Mixer Amplifier

SoundPro Item: 50784 | Part Number: BG-2035

$471.00
$584.00 $471.00
Your Price Sold out
MSRP: $584.00 | MAP: $471.00

Usually ships in 5-7 business days

  • 35W 5-input mixer amplifier
  • Ideal for background music and general announcements in bars, retail stores, and banquet halls
Log in or register for YOUR best price

The BG-2035 from TOA is a 35W 5-input mixer amplifier for background music and general announcement. It is suited for use in bars, retail stores, and banquet rooms, and is equipped with the MOH OUT that permits 2-channel broadcast when used in conjunction with the optional booster amplifier BA-235 (35W) or BA-260 (60W).

View full details
  • Power Source120 V AC, 60 Hz
  • Rated Output35W
  • Power Consumption94 W (rated output), 50 W (based on cULus standards)
  • Frequency Response50Hz - 20kHz
  • THD0.5% or less, at 1kHz, rated output
  • Input
    • Mic: -60 dB*, 600 Ω, electronically balanced, removable terminal block
    • Line 1: -10 dB*/ TEL: -20 dB*
    • Line 1/TEL selectable, 10 kΩ, electronically balanced, removable terminal block
    • Line 2, 3: -10 dB*, 10 kΩ, unbalanced, removable terminal block and RCA jacks Module
  • Output
    • Speaker: 4 Ω, 25 V (18 Ω), 70 V (140 Ω), balanced, removable terminal block
    • MOH: 0 dB*, 600 Ω, balanced, removable terminal block
    • Line: 0 dB*, 600 Ω, unbalanced, removable terminal block
  • Output Regulation2 dB or less, no load to full load (1 kHz)
  • Phantom PowerOn/Off switch for Mic, +24 V DC
  • S/N Ratio
    • Mic: 60 dB or more, Line 1/TEL, Line 2, 3, Module: 75 dB or more
    • (Band Pass: 20 Hz - 20 kHz, Tone Controls: Centered)
  • Control
    • MutingManual mute/Automatic mute
    • Mic gain control
    • Line 1/TEL gain control
    • Line 2 gain control
    • Line 3 gain control
    • Module gain control
    • Bass tone control
    • Treble tone control
    • MOH out gain control
    • Mute control (Manual mute)
    • Remote volume control
    • Mute sense control
    • Line 1/TEL selector switch
    • Phantom power switch (Mic)
    • Auto mute switch (Mic, Line 1/TEL, Module)
    • Mute receive switch (Mic, Line 1/TEL, Line 2, 3, Module)
    • MOH assign switch (Mic, Line 1/TEL, Line 2, 3, Module)
    • Power ON/OFF switch
  • IndicatorPower LED, Signal level LED, Peak LED
  • Operating Temperature0°C to +40°C (32° F to 104° F)
  • Operating Humidity35% to 80%RH (no condensation)
  • Dimensions (WxHxD)10.39" x 3.71" x 10.52"
  • Weight11.68 pounds
