Specifications
Audio
Frequency Response
120 - 20,000 Hz
Sound Pressure Level
85 dB (1 W, 1 m) at installation in 1/2 free sound field
Rated Input
12 W (16 Ohm, high impedance)
Power Handling
90 W (continuous program/4 Ohm); 30 W (continuous pink noise/4 Ohm)
Rated Impedance
4 Ohm, 16 Ohm; 100V line: 830 Ohm (12 W), 1.7 kOhm (6 W), 3.3 kOhm (3 W); 70V line: 420 Ohm (12 W), 830 Ohm (6 W), 1.7 kOhm (3 W), 3.3 kOhm (1.5 W)
Low Frequency Component
8 cm x 5 cm cone-type
High Frequency Component
Balanced dome-type
Enclosure Type
Sealed
Connectivity
Input Terminal
Detachable screw terminal, (+)/(-) 2 each (for bridging connection)
Cable Requirements
Solid or stranded cable: 0.2 - 2.5 mm2 (AWG No. 24 - 14 equivalent)
Construction
Cover Material
Fire-resistant ABS resin, white, paint
Grille Material
Steel plate, white, paint
Adapter Frame Material
Stainless steel
Certifications
Fire Rating
UL 94-V0
Dimensions
Dimensions (W x H x D)
312 x 126 x 90 mm
Weight
Weight
1.5 kg (including adapter frame)
Included Items
Included Accessories
Adapter frame x1, Mounting screw M4 x 25 x4, Hole pattern paper x1
