TOA P-9060DH CU 9000M2 Series 2-Channel 70V Power Amplifier
TOA P-9060DH CU 9000M2 Series 2-Channel 70V Power Amplifier
SoundPro Item: 61555 | Part Number: P-9060DH CU
Usually ships in 5-7 business days
- Dual Operating Modes Support 9000 Series Integration Or Standalone Deployment
- Switchable Input Sensitivity Adapts To -20 dB Or 0 dB Source Levels Per Channel
- CH 1 Mode Switch Routes Single Source To All Channels For Paging Applications
- Startup Mute Protects Speakers From Power-On Transients
- Temperature-Variable Forced-Air Cooling Manages Heat During Extended Operation
- Rack Kit Included For Immediate 19-Inch Rack Installation
The TOA P-9060DH CU is a 2-channel power amplifier delivering 60 watts per channel at 70-volt line output, purpose-built for installed audio applications including commercial facilities, houses of worship, educational campuses, and distributed speaker systems requiring consistent, reliable coverage. Its dual operating modes make it equally effective as a dedicated 9000 series system amplifier or as a fully independent standalone unit, giving system designers flexibility without additional hardware investment.
Input sensitivity is user-selectable between -20 dB and 0 dB per channel via an electronically-balanced, removable terminal block input, and a CH 1 mode switch allows a single source to feed all channels simultaneously for paging or announcement applications. A startup mute function disconnects speaker outputs for approximately five seconds after power-on, protecting downstream loudspeakers from transient noise during system initialization. Forced-air cooling with temperature-variable fan speed keeps thermals managed during extended operation without unnecessary noise at low loads.
With a measured THD of 0.008 percent at rated output and an S/N ratio reaching 105 dB at minimum volume, the P-9060DH CU meets the signal integrity expectations of professional integrators working in noise-sensitive or high-speech-intelligibility environments. The aluminum front panel and SECC steel chassis provide durable rack-mount construction, and a rack kit is included for immediate deployment in a standard 19-inch rack enclosure.
