Bose SC-630TU Paging Horn Speaker for 25V/70V Lines

Bose SC-630TU Paging Horn Speaker for 25V/70V Lines

SoundPro Item: 203770 | Part Number: SC-630TU

$146.00
$180.00 $146.00
Your Price Sold out
MSRP: $180.00 | MAP: $146.00

Usually ships in 5-7 business days

  • Double re-entrant horn supports clear speech output
  • Compression driver aids intelligible paging
  • 25V/70V selector adapts to line configurations
  • Talk-back use supports intercom microphone duty
  • IP65 construction resists dust and moisture
  • Wide temp range suits exposed installations
Log in or register for YOUR best price

The SC-630TU is a compact speaker designed for public address announcement applications, with configuration for both 25V and 70V line systems through a rotary input impedance selector. Its double re-entrant horn and compression driver support clear voice paging and tone signaling distribution.

For outdoor and exposed installations, the unit uses a powder-coated exterior with stainless steel bracket hardware and weather-resistant construction. It is listed to UL 1480 UUMW and ULC-S541, with IEC IP65 compliance for dust and moisture resistance.

View full details

Specifications

Power
Rated Input
30 W
Rated Impedance
70 V line: 170 Ω (30 W), 330 Ω (15 W), 650 Ω (7.5 W) 25 V line: 21 Ω (30 W), 42 Ω (15 W), 170 Ω (3.9 W), 330 Ω (2.1 W), 650 Ω (1.1 W)
Audio
Sound Pressure Level
113 dB (1 W, 1 m at 500 Hz to 2.5 kHz peak level)
Frequency Response
250 Hz - 10 kHz
Polarity
Hot: Black and Red cables, Com: White and Green cables
Construction
Speaker Cable
4-core FPL listed cable 0.6 m (1.97 ft)
(4.8 mm (0.19") in diameter, 600 mm (1.97 ft) in length)
Finish
Horn flare: Aluminum, white (RAL 9010 equivalent), powder coating Reflector horn: ABS resin, white (RAL 9010 equivalent) Rear cover: ABS resin, gray (RAL 7031 equivalent) Bracket, screws and bolts: Stainless steel
Dimensions
285 (W) x 227 (H) x 277 (D) mm (11.22 x 8.94" x 10.91")
Weight
2 kg (4.41 lb)
Compliance
Compliance/Certifications
UL 1480 UUMW, ULC-S541
Dust/Water Protection
IP65
Operating Temperature
-40 °C to +66 °C (-40 °F to 151 °F) (must be free from dew condensation)
Accessories
Optional Accessories
Swivel bracket: YS-151S (Can be used instead of the supplied bracket.)
Note
Avoid installing the speaker in locations which vibrate considerably, or under environments easy to be oil-contaminated.
