TRIPPLITE SMART500RT1U 500Va Ups System Rack/Tower 7 Outlet, 1 Rs232, 1 Usb Snmp Slot

TRIPPLITE SMART500RT1U 500Va Ups System Rack/Tower 7 Outlet, 1 Rs232, 1 Usb Snmp Slot

SoundPro Item: 44085 | Part Number: SMART500RT1U

$514.80
$514.80 $514.80
Your Price Sold out
MSRP: $514.80 | MAP: $514.80

Usually ships in 5-7 business days

  • 1U rack-mount UPS offers complete power protection for small network applications, including telecom, security and digital signage.
  • 1U rack-mount UPS offers complete power protection for small network applications, including telecom, security and digital signage
  • Protects equipment against blackouts, brownouts, transient surges and line noise
  • Protects equipment against blackouts, brownouts, transient surges and line noise
  • Keeps AC power running during blackouts to allow time for file saves and safe shutdown
  • Keeps AC power running during blackouts to allow time for file saves and safe shutdown
  • Maintains continuous 120V nominal output during brownouts as low as 90V
  • Maintains continuous 120V nominal output during brownouts as low as 90V
  • 6 NEMA 5-15R outlets power and protect networking, telecom and other sensitive equipment
  • 6 NEMA 5-15R outlets power and protect networking, telecom and other sensitive equipment
  • Optional WEBCARDLXE network interface allows you 24/7 remote access from anywhere
  • Optional WEBCARDLX network interface allows you 24/7 remote access from anywhere
  • 2-year warranty, 3 year with registration. Note: Registration is required for 3-year warranty.
  • 2-year warranty, 3 year with registration. Note: Registration is required for 3-year warranty.
  • $250,000 Ultimate Lifetime Insurance
  • $250,000 Ultimate Lifetime Insurance
Log in or register for YOUR best price

500VA/300W/120V Battery Backup for PC Networks, Security Systems or Digital Signage
The SmartPro® line-interactive SMART500RT1U UPS system with AVR protection provides reliable battery backup and AC power protection against blackouts, brownouts, surges and line noise that can damage valuable electronics or destroy data. The 120V battery backup is ideal protection for point-of-sale and kiosk applications, a small business VoIP network, or rack-mount equipment in your server room or network closet.

Allows Time to Back Up Critical Files During a Blackout
Backup support allows you to work through short power failures and gives you enough time to safely save files and shut down your system in case of a prolonged blackout. Backup time varies according to load, but the line-interactive UPS system should keep a half load (150W) powered as long as 14 minutes and a full load (300W) up to three minutes.

6 NEMA Outlets Protect Your Connected Components
Six 5-15R outlets provide battery backup, 567 joules of network-grade surge protection and voltage regulation for your crucial components. Five outlets are UPS-supported, and one is surge-only to connect peripherals not requiring battery backup. One UPS-supported outlet is switchable, allowing you to power its connected device on and off remotely to reset or reboot it or to shed a less significant load to extend battery runtime for more critical equipment.

Automatic Voltage Regulation (AVR) Corrects Low-Voltage Conditions
AVR protects your equipment from incremental hardware damage, data loss and performance problems caused by brownouts. The SMART500RT1U maintains regulated 120V nominal output during brownouts as low as 90V, while keeping the battery fully charged and ready to take over in case of power failure. The fast-to-recharge internal batteries are field-replaceable and hot-swappable.

Optional WEBCARDLX Network Interface Offers 24/7 Access
An accessory slot accommodates the optional Java-free HTML5-based WEBCARDLX interface (sold separately), which enables full remote access for site power and UPS status monitoring, configuration, control and email notifications via secure web browser, SNMP, telnet or SSH. It supports 10/100 Mbps auto-sensing for optimal communication with an Ethernet network. Automated alerts help prevent accidental overloads, power loss and downtime.

Premium Protection from EMI/RFI Line Noise Helps Your Equipment Perform Better
This UPS system filters out disruptive electromagnetic and radio frequency interference that can inflict hardware damage or data loss. This EMI/RFI filtering also helps your connected components perform better and last longer.

Designed for High Efficiency to Help You Save Money and Protect the Environment
A 97% efficiency rating reduces BTU emissions, energy consumption and, ultimately, your energy costs.

View full details

Specifications

'General Information
Manufacturer
Tripp Lite
Manufacturer Part Number
SMART500RT1U
Brand Name
Tripp Lite
Product Line
SmartPro
Product Name
SmartPro 500VA Rack/Tower UPS
Product Type
Line-interactive UPS
Technical Information
Plug/Connector Type
NEMA 5-15P
Receptacles
7 x NEMA 5-15R
Switching Time
4 ms
Power Description
Load Capacity
500 VA/300 W
Input Voltage
110 V AC
Input Voltage Range
120 V AC Single-phase
Output Voltage
120 V AC Single-phase
Frequency
60 Hz
Waveform Type
Pulse-width Modulated Sine Wave
Surge Energy Rating
480 J
Filtering
EMI / RFI
Management
Network Management
SNMP Manageable Optional
Overload Protection
Via 15A input breaker
Alarm
On Battery
Overload
UPS Fault
Low Battery
Emergency Power OFF
Yes
Controls/Indicators
Status Indicators
5 front panel LEDs - Green POWER LED, 3 color BATTERY CHARGE LED, 3 color OUTPUT LOAD LEVEL LED, red BATTERY WARNING LED.
Interfaces/Ports
Interfaces/Ports
1 x USB
1 x DB-9 Serial
Modular Slots
4 x Communications Slot
Battery Information
Batteries
Sealed Lead Acid User-replaceable Hot-swappable
Backup/Run Time
0.08 Hour 500 W Full Load
0.28 Hour 250 W Half Load
Battery Life
26297.44 Hour to 52594.88 Hour
Battery Recharge Time
4 Hour
Environmental Conditions
Temperature
32°F (0°C) to 104°F (40°C) Operating
5°F (-15°C) to 122°F (50°C)
Humidity
0 to 95% Non-condensing Relative Humidity
Physical Characteristics
Color
Black
Form Factor
1U Tower/Rack Mountable
Power Cord/Cable
10 ft
Dimensions
17.50" Width x 11.75" Depth
Weight (Approximate)
18.80 lb
Miscellaneous
Package Contents
SMART500RT1U UPS System Mounting hardware Cabling for USB & DB9 monitoring and EPO switching PowerAlert unattended shutdown and UPS/Power monitoring software Warranty information and instruction manual
Additional Information
SMART500RT1U line interactive UPS offers battery derived sine wave AC output during power outages, voltage regulation during brownouts, plus network-grade AC surge suppression 500VA / 300 watt power handling capability compatibile with networking, telecom and other sensitive electronic devices Supports 1U rackmount installation in 2 or 4 post rack enclosures, upright tower placement also supported - mounting accessories included Large internal batteries offer runtimes of 17 minutes at half load (250VA / 150 watts) and 5 minutes at full load (500VA / 300 watts) Maintains regulated 120V nominal output during brownouts as low as 90V Includes 6 UPS-supported outlets, with one single outlet load bank that can be powered off and back on again via software interface. One additional surge-only outlet powers accessories not requiring battery support PowerAlert UPS monitoring and unattended shutdown software enables configurable network broadcast messaging, pager & email notification, event logging and running user-defined script commands Offers simultaneous monitoring by up to 3 directly-connected devices through included USB, DB9 and SNMP* interfaces (*requires optional SNMPWEBCARD), or the monitoring of any number of additional UPS systems over IP with included PowerAlert monitoring software. Free PowerAlert enterprise management software is also available for select opportunities Communications ports support messaging of UPS and line power status, including on-battery, low-battery, power restored, AC line voltage, DC battery voltage and remaining battery capacity Supports timed inverter shutoff after unattended shutdown, activate self-test and UPS output power control for scheduled or immediate reboot of connected devices Supports Tripp Lite's WatchDog software application to restore unresponsive programs by systematically restarting applications, operating systems and ultimately rebooting completely locked computers by momentarily switching UPS power off and back on again (requires optional WATCHDOGSW) Built-in accessory slot supports SNMP with optional SNMPWEBCARD adapter Emergency Power Off (EPO) interface with cable Multi-function audible alarms and set of 5 front panel LEDs Network-grade AC surge suppression Attractive all-black color scheme UPS battery set ships fully assembled and ready for installation, no time consuming connection of internal batteries by user is necessary Two year warranty with $250,000 connected equipment insurance (USA & Canada only)
System Requirements
TYPICAL APPLCIATIONS: Ideal for protection of fileservers, network accessories and telecommunications equipment in server rooms, internetworking closets, co-location racks, kiosks and a variety of other locations. Common applications include any mix of servers, workstations, hubs, routers, concentrators, IP telephony and traditional PBX switching systems.
Software Included
PowerAlert Software
Warranty
Standard Warranty
2 Year
