Specifications
Display
Display Diagonal Size
86"
Resolution
3840 x 2160
Display Technology
Direct LED, TFT
Brightness
500 nits
Contrast Ratio
1200:1
Color Support
1.07 Billion Colors
Response Time
6.5 ms
Viewing Angle
178°/178°
Aspect Ratio
16:9
Screen Type
Anti-glare
Audio
Speakers
Yes
Audio Output
Yes
Connectivity
HDMI Ports
5
DisplayPort Ports
1
VGA Ports
1
USB Ports
Yes
USB Type-C
Yes
RS232
Yes
RJ45/LAN
Yes
SD/SDHC Slot
Yes
OPS Slot
Yes
Power
Voltage Required
100-240V AC
Operational Power Consumption
111.45 Watts
Off Mode Power Consumption
0.5 Watts
Dimensions
Width
77.05"
Depth
3.36"
Height
46.36"
Weight
Product Weight
128.88 lbs
Mounting
VESA Mount Pattern
800 x 600 mm
Environmental
Operating Temperature Range
0°C to 40°C
Operating Humidity Range
20% to 80% RH non-condensing
Shipping
Package Weight
156.56 lbs
Package Dimensions
83.07" x 8.86" x 51.54"
Software
Included Software
myViewBoard for Android, myViewBoard for Windows, AirSync, Manager
Included Items
Power Cord
3 meters
USB Type-C Cable
1.8 meters, USB-IF certified
USB Touch Cable
3 meters
Passive Touch Pens
2 (VB-PEN-002)
HDMI Cable
3 meters, HDMI LA certified
RS232 Adapter
1
Clamps
5
Camera Plate
1
Screws
8
Remote Controller
1
AAA Batteries
2
Quick Start Guide
Yes
Compliance Statement
Yes
