Waves LV1 Classic Live Mixing Console
Waves LV1 Classic Live Mixing Console
SoundPro Item: 145683 | Part Number: AIOCL
In stock and ready to ship
- 64 mono/stereo input channels
- 44 mono/stereo buses: 8 groups, 24 auxes, 8 matrices, 3 master, cue
- Double Precision 32-bit floating point mix engine (44.1-96 kHz)
- Latency as low as 0.8 ms
- 21.5” multi-touch screen with 1000 Nit brightness
- 16+1 motorized 100 mm Alps faders
- 16+1 precision encoders, with mini-displays including per-channel LCD metering, and Select/Mute/Solo keys
- 16 layers with utility keys and tempo pad
- 16+2 customizable keys
- 16 Waves Signature Preamps with mic/line inputs
- 12 line outputs, 2 AES3 outputs, AES3 SRC input
- Built-in SoundGrid server (Extreme Server-grave) handles processing
- Add more IOs: Up to 14 devices including Analog, AES3, Dante, MADI
- Add up to 3 processing servers and 4 backup servers
- 4 SoundGrid switch ports: 2 Ethercon + 2 Rj45
- Hi-power H/P output with 1/4” jack + minijack
- HDMI / 8 USBs / remote network
- 12v XLR4 lamp option
- Dual power supply for redundancy
- 8-slot rack hosts 8 plugins per input channel + all mix channels
- Plugins included with the console: Waves Tune Real-Time, F6 Dynamic EQ, eMo Q4 EQ, eMo D5 Dynamics, eMo F4 Filter, GEQ, X-FDBK, Primary Source Expander, R-Comp, R-Bass, H-Delay, Doubler, R-Verb, TrueVerb, GTR3, Magma Tube Channel Strip, eMo Generator
- 160 additional award-winning Waves plugins available as upgrades
- Immersive in-ear mixing available as software upgrade (eMo IEM)
- Dugan auto-mixing available as software upgrade
- Custom options for mixing layout
- Intuitive control over each channel’s parameters
- Patch system-wide connections
- Custom colors per channel
- Unicode multi-language support
- Up to 1000 scenes with Recall Safe and Scope Filters
- 8 Mute groups and 16 Link DCAs with Spill function
- Digital preamp control with local V-Gain tracking for sharing
- Multiple outputs per channel with delay alignment controls
- Record 16 tracks locally to USB / 128 tracks to remote computers
- Stereo playback from USB
- Remote control apps for mobile & tablet, for both FOH and stage
eMotion LV1 Classic builds upon the proven quality of the Waves LV1 mixer engine, which until now has been available as a modular system only. It delivers the LV1’s proven advantages-sonic excellence, fully integrated Grammy®-winning processing, intuitive UI-in the preferred console form factor and workflow of live sound engineers worldwide.
