Specifications
Certifications
NEC UL Rating
CMR, CMG
Dimensions
AWG Size
22
Cabling Lay Length
2.5"
Nominal Cable Diameter
0.127"
Electrical
UL Voltage Rating
300
Construction
Insulation Color Code
1.Black 2.Red
Shield Type
overall 100% aluminum foil
Environmental
Operating Temperature
-4°F to 140°F (-20°C to 60°C)
UL Flammability
UL1666 Vertical Shaft
CSA Flammability
FT4
General
Conductors
2
Conductor Stranding
7x30
Conductor Type
bare copper
Nominal DCR
17Ohm/1000ft
Twists/foot
4.8
Insulation Type
thermoplastic
Insulation Thickness
0.007"
Drain Wire Type
tinned copper
Drain Wire AWG
24 AWG
Nom. cap. Between Conductors
34pF/ft
Nom. cap. Conductor to Shield
67pF/ft
Jacket Type
PVC
Jacket Thickness
0.017"
Ratings
RoHS Compliant
