Wisycom BFA-B-F2 Wideband Active Amplifier with Tunable Filter | Connector: BNC

Wisycom BFA-B-F2 Wideband Active Amplifier with Tunable Filter | Connector: BNC

SoundPro Item: 150833 | Part Number: BFA-B-F2

$840.00
$935.00 $840.00
Your Price Sold out
MSRP: $935.00 | MAP: $840.00

Usually ships in 5-7 business days

  • Huge reception band: 410-1300 MHz
  • Remote controllable thru coax cable
  • RF gain from -12 to +27 dB (1 dB step)
  • Easy configuration thru a TFT display
  • Tunable filter for interference control
  • Antenna off for RF zone disabling
  • Fixed band saw filter
  • Pass thru DC selectable for device cascading
  • 3 High Pass & 3 Low Pass filters
  • Waterproof with gasket sealing
Log in or register for YOUR best price

The Wisycom BFA is an in-line filter, and booster for UHF. For use with certain Wisycom wireless products. The BFA-F2 has three software selectable filter options, allowing for a wide range of use in microphone receive applications. Selectable Highpass options 470/520/550 MHz with a lowpass option 617/663/698 MHz. The second filter option is a 40MHz bandwidth tunable filter, utilizing 1MHz steps from 430MHz to 730MHz. The final filter is a fixed saw filter for the United States from 940MHz to 960MHz. The BFA additionally offers adjustable gain from a -12dB attenuation to +27dB boost. When paired with a Wisycom MAT288/244, SPL2208/2216, or MRK16 the BFA can be remote controlled. The BFA requires +12V 100mA for full operation. BFA-B-F2 is available with a BNC or N-Type connector for easy connection.

View full details

Specifications

Electrical
Operating Voltage Range
9.5 - 16 Vdc
Audio
Impedance
50 Ω
Booster Gain
-12 - 27 dB typical (1 dB step selection)0.8 dB attenuation (bypassed)
Shipping
Weight
250g
General
Frequency Ranges
430 - 1160 MHz
SWR
Tunable: 430 - 730 MHz (UHF), 40MHz of BWFixed: 940 - 960 MHz or 1240 - 1260MHzSelectable Filter HP: 470/520/550 MHz + LP: 617/663/698 MHz
Booster Steps
± 1 dB, in the whole working window
Power Supply
+12 V, 100mA
Indicators
Display
TFT - transflective (176 x 176 pixels, RGB)
