WYRESTORM EXF-300-H2 18Gbps Hdmi Hdcp 2.2 Bidirectional Ir Or Rs-232 Over Om3 Multi-Mode

WYRESTORM EXF-300-H2 18Gbps Hdmi Hdcp 2.2 Bidirectional Ir Or Rs-232 Over Om3 Multi-Mode

SoundPro Item: 94388 | Part Number: EXF-300-H2

$1,006.00
$1,006.00 $1,006.00
Your Price Sold out
| MAP: $1,006.00

Usually ships in 5-7 business days

  • Extends 18Gbps HDMI transmissions using multimode fiber up to 300m/984ft
  • Compatible with the latest HDR-10 content and 4K/60 4:4:4
  • HDCP 2.2 compliant
  • Passes IR or RS-232 control signals bidirectionally
  • Ideal for long distance transmission in environments with high-levels of EM or RF interference
Log in or register for YOUR best price

LET THERE BE LIGHT

Having a physical form, copper cable causes attenuation and weakens a signal with every metre that it has to travel. Pixel-perfect transmission of HDMI content as light is now possible over optical fiber up to 300m/984ft.

HDMI 2.0 MAXED OUT

The highest possible bandwidth that currently exists according to the HDMI 2.0 specification can be sent using the latest optical transmission technology.

HIGH FRAME RATE HDR

HDR Content has recently enjoyed an up-shift in refresh rates after starting its life at 24Hz on UHD Blu-Ray discs. High frame-rate HDR is now available at 60Hz on certain discs and via games consoles like the Xbox One X.

HIGH RESISTANCE TO EM OR RF INTERFERENCE

Optical transmission is immune to EM and RF, meaning that electronically "noisy" environments such as industrial or retail premises have historically been difficult for copper as a medium. Using optical transmission over a multi-mode fiber core, the EXF-300-H2 ensures a solid, stable signal over nearly 1000ft.

View full details

Specifications

'General Information
Manufacturer
WyreStorm
Manufacturer Part Number
EXF-300-H2
Brand Name
WyreStorm
Product Model
EXF-300-H2
Product Name
EXF-300-H2 Video Extender Transmitter/Receiver
Product Type
Video Extender Transmitter/Receiver
Technical Information
Connectivity Technology
Wired
Number of Input Devices Supported
1
Number of Output Devices Supported
1
Maximum Operating Distance
984 ft
Video
Graphics Modes
4K
Maximum Video Resolution
4096 x 2160
Interfaces/Ports
HDMI In
Yes
HDMI Out
Yes
Number of HDMI Inputs
1
Number of HDMI Outputs
1
Physical Characteristics
Transmitter Height
0.79"
Transmitter Width
5.91"
Transmitter Depth
2.93"
Receiver Height
0.79"
Receiver Width
5.91"
Receiver Depth
2.93"
Form Factor
Rack-mountable
Desktop
Transmitter Weight (Approximate)
10.58 oz
Receiver Weight (Approximate)
10.58 oz
Miscellaneous
Environmentally Friendly
Yes
Environmental Certification
RoHS
Country of Origin
China
Warranty
Limited Warranty
5 Year
