Yamaha MGX12 Compact 18-Channel Digital Mixing Console | Black

Yamaha MGX12 Compact 18-Channel Digital Mixing Console | Black

SoundPro Item: 202442 | Part Number: MGX12 B

$799.99
$985.00 $799.99
Your Price Sold out
MSRP: $985.00 | MAP: $799.99

In stock and ready to ship

  • Versatile Digital Mixing Console – Designed for live sound, streaming, recording, and installed sound applications.
  • Touchscreen Interface with Physical Controls – Touch-panel GUI, rotary controls, and 12 faders provide intuitive operation.
  • Premium MGX Mic Preamps – Four mic/line combo inputs with high gain range and low distortion.
  • Built-In DSP Effects – Includes processing tools such as gate, compressor, EQ, reverb, amp simulator, and voice changer.
  • USB Audio Interface – Supports 18-track recording and playback via USB MAIN and 2-track recording/playback via USB SUB.
  • Bluetooth Audio Connectivity – Allows wireless audio sources to be integrated into mixing, streaming, or recording setups.
  • Customizable Sound Pads – Eight pads can trigger sound effects or function as user-defined keys.
  • microSD Recording and Playback – Records up to 16 tracks and plays back 2 tracks directly from a microSD card.
Log in or register for YOUR best price

The Yamaha MGX12 is a compact digital mixing console designed for live sound, streaming, production, and installed sound applications. It combines flexible mixing capabilities, onboard DSP processing, and premium audio performance in a portable design.

Featuring a touch-panel GUI with physical controls, the MGX12 allows quick and intuitive operation while offering extensive I/O options, USB audio connectivity, Bluetooth integration, sound pads, and microSD recording. With professional effects, flexible routing, and high-performance AD/DA conversion, it delivers refined sound quality across a wide range of environments.

View full details

Specifications

MIXING CAPACITY
Mono Channels
8
Stereo Channels
4
FX Channels
2
Sound Pad
Dedicated sound pad channel
BUS STRUCTURE
Mix Buses
8 MIX buses
FX Buses
2 FX buses
Cue Bus
1 CUE bus
Stereo Bus
1 STEREO bus
INPUTS
Mic/Line Inputs
4 combo inputs with MGX mic preamps
Line Inputs
8 line inputs
OUTPUTS
Main Outputs
2 XLR outputs
OMNI Outputs
6 TRS OMNI outputs
Headphone Outputs
4 headphone outputs
AUDIO PERFORMANCE
Mic Preamp Gain Range
86 dB
Stereo Output Dynamic Range
125 dB
CONNECTIVITY
USB MAIN
18-track recording; 18-track playback
USB SUB
2-track recording; 2-track playback
Bluetooth
Wireless audio input support
microSD Recording
Up to 16-track recording; 2-track playback
CONTROL
Faders
12 x 60 mm faders
Touchscreen
Touch LCD interface
Custom Controls
8 pads; 4 customizable knobs; Touch and Turn control knob
PHYSICAL
Weight
8.6 lb
