Specifications
Connectivity
Control Unit Interface
USB 2.0 High Speed (Type B), Bluetooth, NFC (Near Field Communication)
Audio Input
Stereo RCA pin
Audio Output
Stereo RCA pin
External Speaker Terminal
RCA pin x 2
Audio
Microphone Type
Unidirectional x 3, 360 degree coverage
Speaker Type
Full-range Speaker x 1
Maximum Volume
95 dB at 0.5 m (1.6 ft)
Frequency Bandwidth
100 Hz - 20,000 Hz
Audio In Maximum Input Level
1.6 dBV
PA Microphone Maximum Input Level
1.6 dBV
Microphone Maximum Input Level
-38.4 dBV
Audio Out / External Speaker Maximum Output Level
0.5 dBV
Signal Processing
Processing Features
Adaptive echo canceller, Noise reduction, Automatic tracking, Automatic gain control, Automatic room EQ, Dereverberation, Automatic audio tuning
Electrical
Power Consumption (1 Microphone)
20 W
Power Consumption (5 Microphones)
35 W
Power Source (USA / Canada)
AC 120 V, 60 Hz
Power Source (UK / Europe / Russia)
AC 220-240 V, 50 Hz
Dimensions
Control Unit (W x H x D)
332 x 95 x 162 mm (13.1 x 3.74 x 6.38 in)
Microphone (W x H x D)
136 x 36 x 136 mm (5.35 x 1.42 x 5.35 in)
Weight
Control Unit Weight
1.8 kg (4.0 lbs)
Microphone Weight
0.4 kg (0.9 lbs)
Environmental
Operating Temperature
0 - 40 degrees C (32 - 104 degrees F)
Operating Humidity
20 - 85% (no condensation)
Compatibility
Supported OS
Windows 11, Windows 10 (32bit/64bit), macOS 13, macOS 12, macOS 11, Chrome OS
Voice Guidance Languages
English, Japanese, Chinese, Korean, French, Spanish, German
Included Items
Accessories
Power cable 3 m (9.8 ft), USB cable 5 m (16.4 ft), Microphone cable 5 m (16.4 ft), Quick Start Guide
Identifiers
Optional Extension Microphone
YVC-MIC1000EX
