Specifications
Dimensions
Dimensions (WxHxD)
12" x 19.5" x 11.8"
Electrical
Power Consumption
60 W (1/8 power), 18 W (Idle)
Power Requirements
100 V, 100-120 V, 220-240 V, 110/127/220 V (Brazil), 50/60 Hz
Audio
Speaker Type
2-way, Bi-amped Powered Speaker, Bass-reflex
Crossover
1.9 kHz: FIR-X tuning™ (linear phase FIR filter)
OUTPUT
XLR3-32 x 1 (CH1 Parallel Through or CH1+CH2 Mix)
Connectivity
Max. Output Level (measured Peak, IEC Noise @1m)
128 dB SPL
Pole Socket
Φ35 mm x1 (Bottom)
Construction
Amplifier Class
Class D
Cabinet Material
plywood
Finish
durable polyurea painting, black
Included Items
Components
LF, HF
Shipping
Weight
33.1 pounds
General
Frequency Range (-10dB)
52Hz - 20,000Hz
Coverage Area (HxV)
90° x 60° (rotatable)
Dynamic
700 W (LF: 500 W, HF: 200 W)
Continuous
325 W (LF: 260 W, HF: 65 W)
Cooling
fan cooling, 4 speeds
A/D D/A Converters
24 bit 48 kHz Sampling
HPF
OFF, 100 Hz, 120 Hz 24dB/Oct
D-CONTOUR
FOH/MAIN, MONITOR, OFF
INPUT2
Combo x 1 + RCA pin x 2 (Unbalanced)
Handle
top (1)
Rigging
Top x 2, Rear x 1 (Fit for M10 x 30 - 50 mm Eyebolts)
Inputs
INPUT1
Combo x1
