• Yamaha MG12 12-Channel Analog Mixer
1 1

Yamaha MG12 12-Channel Analog Mixer

Yamaha MG12 12-Channel Analog Mixer

SoundPro Item: 58835 | Part Number: MG12

$324.99
$421.00 $324.99
Your Price Sold out
MSRP: $421.00 | MAP: $324.99

In stock and ready to ship

  • 12-Channel analog mixing console
  • Internal universal power supply for world-wide use
  • Optional Rack Mount Kit RK-MG12 Available
  • Metal chassis takes a beating from heavy-duty wear
  • Max. 6 Mic / 12 Line Inputs (4 mono + 4 stereo)
  • 2 GROUP Buses + 1 Stereo Bus
  • 2 AUX (incl. FX)
  • "D-PRE" mic preamps with an inverted Darlington circuit
  • 1-Knob compressors
  • PAD switch on mono inputs
  • +48V phantom power
  • XLR balanced outputs
Log in or register for YOUR best price

The MG12 from Yamaha is a 12-channel analog mixer that features +48V phantom power, XLR balanced outputs, a sturdy metal chassis, an internal universal power supply, and much more!

View full details
  • Monaural/Stereo CH High Pass Filter 80 Hz 12 dB/octave
  • Monaural/Stereo CH Equalization (Turn over /roll-off frequency of shelving, 3 dB below maximum variable level)
    • ±15 dB (Max. Variation)
    • HIGH: 10 kHz (shelving)
    • MID: 2.5 kHz (peaking)
    • LOW: 100 Hz (shelving)
  • Internal Digital Effect
    • 16 programs, Parameter control
    • FOOT switch (ON/OFF)
  • Phantom Power Supplied when Phantom +48 V switch is ON. (XLR-type input jacks)
  • Monaural/Stereo Input PEAK Indicator On each channel: red indicator lights if post-EQ signal (on ST channels, if either post-EQ signal or post-mic-amp signal) comes within 3 dB of the clipping level.
  • Level Meters
    • Two 12-points LED level meters [ST (L, R)]
    • Peak point: red indicator
    • +5, +3, +1, 0: yellow indicators
    • –1, –3, –5, –7, –10, –15, –20: green indicators
  • Options Footswitch (FC5)
  • Power Consumption 36 W
  • Dimensions (W × H × D) 322 mm × 108 mm × 416.6 mm
  • Weight 5 kg
