Specifications
Electrical
Max Input Voltage
+25dBu
Power Requirements
100V - 240V 50Hz/60Hz
Audio
THD
0.01%
Frequency Response
+0.5, -1.5dB (8Ω, 1W, 35Hz to 20kHz)
Crosstalk
≤ -60dB (8Ω, 1kHz, Half power, Input 150Ω shunt A-weighted)
Input Impedance
20kΩ (balanced)
Connectivity
Analog Input
XLR-3-31 x 4
Control Ports
RJ45 x 1
Fault Output
Euro block 8pin (mini) x2 (GPI x 4, GPO x 6, +5V x 2)
Construction
Amplifier Class
Class D, single ended output
General
16Ω
300W x 4
8Ω
600W x 4 (1800W x 2 in BRIDGE mode)
4Ω
900W x 4 (2600W x 2 in BRIDGE mode)
2Ω
1300W x 4
S/N Ratio
109dB (8Ω, Gain setting = 32dB, A-weighted)
Sampling Frequency Rate
96kHz
A/D Converters
32-bit linear, 64 times over sampling
D/A Converters
32-bit linear, 128 times over sampling
Digital I/O
Dante Interface etherCON x 2 (Redundant/Daisy Chain)
Speaker Ouput
Neutrik speakON NL4 x 4
AC
AC inlet (powerCON 20A) x 1
Other
Remote
