Specifications
Dimensions
Dimensions (WxHxD)
18.88x3.44x15.25"
Electrical
Max Input Voltage
+24dBu
Power Consumption
310W (1/8 max power), 60W (idling)
Audio
THD
0.1%, 0.3% (half power)
Frequency Response
20Hz to 20kHz (+/-1dB)
Crosstalk
less than -60dB
Input Impedance
20kΩ (balanced), 10kΩ (unbalanced)
Connectivity
Speaker Output Ports
Neutrik speakON NL4 x2, Binding post x2 pairs, 1/4" PHONE(TS) x2
Line Input
XLR-3-31 x2, 1/4 "PHONE(TRS) x2
I/O Connectors
USB 2.0 standard A-connector, AC inlet
Construction
Amplifier Class
Class D, balanced output circuit
Shipping
Weight
16.31 lbs (7.4 kg)
General
8Ω
10,000W x 2
4Ω
12,000W x 2
2Ω
700W x 2
Internal Sampling Frequency Rate
48kHz
A/D D/A Converters
24-bit linear, 128 times over sampling
S/N Ratio
101dB A-weighted
Presets
8 user amplifier presets
Cooling
16 step variable speed fan x2, front to rear airflow
Audio Performance
Latency
1.5msec (analog input to speakers)
