Yamaha RM-CG Ceiling Array Mic With Dante And Multi-Beam Tracking | White

Yamaha RM-CG Ceiling Array Mic With Dante And Multi-Beam Tracking | White

SoundPro Item: 145064 | Part Number: RM-CG-W

$4,949.99
$4,950.00 $4,949.99
Your Price Sold out
MSRP: $4,950.00 | MAP: $4,949.99

Usually ships in 5-7 business days

  • Multi-Beam Tracking Follows Active Speakers For Natural, Lively Conversation
  • Dante Network Audio Over A Single Cat 5e Cable Simplifies Plenum Wiring
  • Onboard AEC, Noise Reduction, And Dereverberation Remove Need For External DSP
  • Three Mounting Methods Support Flush, Wire, And VESA Ceiling Installations
  • PoE Power Delivery Eliminates Separate Power Runs To The Ceiling
  • IP5X Dust Protection And UL2043 Plenum Rating Meet Commercial Install Requirements
  • Auto-Detection With RM-CR Remote Conference Processor Speeds Multi-Room Commissioning
Log in or register for YOUR best price

The Yamaha RM-CG is a ceiling array microphone built for AV integrators and systems designers deploying conferencing infrastructure in corporate boardrooms, huddle spaces, training rooms, and government facilities. It combines multi-beam tracking, adaptive echo cancellation, noise reduction, dereverberation, auto mixing, and automatic gain control into a single ceiling-mounted unit, eliminating the need for a separate DSP appliance in many configurations.

A single shielded Cat 5e or higher cable carries both power via PoE and bidirectional Dante audio, dramatically simplifying plenum wiring and reducing termination points compared to analog microphone arrays with separate power and signal runs. Three supported mounting methods, ceiling flush, wire suspension, and VESA, give installers flexibility across slab, T-bar, and suspended ceiling environments without additional brackets.

Automatic detection and configuration with the Yamaha RM-CR Remote Conference Processor makes commissioning straightforward for multi-room rollouts. Up to 14 RM-CG units can connect to a single RM-CR, scaling coverage across large or divided spaces. IP5X dust protection and UL2043 plenum rating, both with the included terminal cover, meet the environmental and code requirements of commercial and government installations where analog alternatives often fall short.

View full details

Specifications

Certifications
Dust Protection
IP5X (with terminal cover)
Plenum Rating
UL2043 (with terminal cover)
Dimensions
Width
560 mm
Depth
560 mm
Height
90 mm (includes protrusion/microphone panel: 22 mm)
Weight
Unit Weight
5.6 kg
Electrical
Power Requirements
PoE (IEEE 802.3af)
Maximum Power Consumption
7.2 W
Audio
Audio I/O
1in/2out; In1=AEC reference signal / Out1=output of beam mix, Out2=output of beam mix (simple processed)
Sampling Rate
48 kHz
Bit Depth
24 bit
Latency
58 ms (including signal processing), 22 ms (low-latency mode)
Frequency Response
160 Hz - 16 kHz (-10 dB)
Maximum Input Level of SPL (0dBFS)
117.8 dB SPL
Self Noise
-0.8 dBA SPL
SN Ratio (Ref. 94 dB SPL at 1 kHz)
94.8 dBA
Sensitivity
-23.8 dBFS/Pa
Dynamic Range
118.6 dBA
Signal Processing
Multi Beam Tracking, Adaptive Echo Canceler, Noise Reduction, Dereverberation, Auto Mixer, Auto Gain Control, Parametric EQ, Output Gain Adjustment
Connectivity
Connector
RJ45
Network
Dante, Remote Control, WebUI, PoE
Cable Requirements
Cat 5e or higher (STP)
Construction
Color
White
Mount
Ceiling mount, Wire mount, VESA mount
Indicator
Front Indicator (Mute/Unmute and Status), Network Port Indicator
Environmental
Operating Temperature
0°C - 40°C
Operating Humidity
30% - 90% (no condensation)
Storage Temperature
-20°C - 60°C
Storage Humidity
20% - 90% (no condensation)
Compatibility
Maximum Device Number with RM-CR
14 (without VXL1-16P, up to 16)
Included Items
Accessories
Construction description, (Guarantee), Grille x 1, Screws for grille (M3 x 8 mm) x 5, Screw cover x 4, Cutting template x 1, C ring x 1, Screws for C ring x 2, Hanger angle x 1, Screws for hanger angle (M4 x 20 mm) x 5, Terminal Cover x 1, Safety wire x 1, Binding band x 1, Clamp plate x 2
