Specifications
Dimensions
Width
140 mm
Depth
140 mm
Height
41.5 mm
Weight
Unit Weight
310 g
Electrical
Power Requirements
PoE (IEEE 802.3af)
Maximum Power Consumption
4.5 W
Audio
Frequency Response
160 Hz - 16 kHz (-10 dB)
Maximum Input SPL (0 dBFS)
106.8 dB SPL
Self Noise
6.3 dBA SPL
SN Ratio (Ref. 94 dB SPL at 1 kHz)
87.7 dBA
Sensitivity
-12.8 dBFS/Pa
Dynamic Range
100.5 dBA
Sampling Rate
48 kHz
Bit Depth
24 bit
Latency
46 ms (standard, except toroidal); 50 ms (toroidal); 20 ms (low-latency, except toroidal); 23 ms (low-latency, toroidal)
Audio I/O
1 in x 2 out; In1=AEC reference signal, Out1=beam mix output, Out2=beam mix simple processed output
Performance
Signal Processing
Auto Voice Tracking, Selectable Polar Pattern (Cardioid, Hyper-cardioid, Super-cardioid, Omnidirectional, Bidirectional, Toroid), Adaptive Echo Canceller, Noise Reduction, Dereverberation, Auto Mixer, Auto Gain Control, Parametric EQ, Output Gain Adjustment
Maximum Device Number with RM-CR
14 (without VXL1-16P, up to 16)
Connectivity
Ethernet Port (Ether1)
Dante Audio, Dante Control, Remote Control, Web UI, PoE
Cable Requirements
Cat 5e or higher (STP)
Construction
Color
White
Environmental
Operating Temperature
0 - 40 degrees C
Operating Humidity
30% - 90% (No condensation)
Storage Temperature
-20 - 60 degrees C
Storage Humidity
20% - 90% (No condensation)
Identifiers
Indicator
Mute Indicator (Mute/Unmute), Status Indicator (Ring), Network Port Indicator
Included Items
Accessories
Installation Manual, Table-top mounting adapter, 3x Screw for mounting, 3x Spacer
