Specifications
Dimensions
W 89.0 mm x D 89.0 mm x H 171.2 mm (including rubber feet and to center of gooseneck mic)
Weight
140 g (including battery)
Power Requirements
Rechargeable Li-ion Battery 3.6 V 2350 mA/h, For Charge I/F : USB Type C, RM-WCH Charger I/F (4pin)
Maximum Power Consumption
5.0 V 0.7 A
Indicator
Microphone indicator (3 colors) x1, Ring indicator (3 colors) x1, Battery indicator (3 colors) x1
Buttons
Microphone button x1, Battery button x1, PAIR button x1
I/O
USB Type C (for battery charging) x1, Charger I/F (4pin) x1
Audio Specifications
Latency
30 ms - 35 ms nominal (without signal processing in High Quality mode), 110 ms nominal (with signal processing in High Quality mode)
Maximum Input Level of SPL (0dBFS)
106.2 dB SPL
Self Noise
-19.3 dBA SPL
SN Ratio (Ref. 94 dB SPL at 1 kHz)
113.3 dBA
Directivity
Unidirectional (Sensitivity: 90°)
Frequency Response
160 Hz - 16 kHz
Sensitivity
-12.2 dBFS/Pa
Dynamic Range
125.5 dBA
Wireless Specifications
Radio Method
1.9 GHz DECT standard
Radio Frequency Range
USA/Canada: 1920.0-1930.0 MHz, Japan: 1893.5-1906.1 MHz, EU/Australia/New Zealand/Norway/UK/Hong Kong/UAE/Singapore: 1880.0-1900.0 MHz
Maximum RF Power Level (EIRP)
USA/Canada: 20.1 dBm, Japan: 27.0 dBm, EU/Australia/New Zealand/Norway/Sweden/Finland/Denmark/UK/Hong Kong: 25.9 dBm, UAE/Singapore: 23.8 dBm
Maximum Coverage Distance
50 m (depends on the usage environment)
Encryption
AES (256-bit)
