Specifications
Dimensions
Dimensions (WxHxD)
9.5x12.3x8.5" (239x310x215mm), with handle
Electrical
Power Consumption
10W (Idle), 30W (1/8 power)
Power Requirements
100-240 V 50/60 Hz
Audio
OUTPUT
XLR3-32 (INPUT 1-3 mix)
Speaker Type
Coaxial speaker with compression driver
Crossover
1.8 kHz (FIR-X)
Connectivity
Bluetooth
Ver.5.0, A2DP (SBC, AAC), Class 1
Input Channel Functions
Hi-Z: CH2
Output Channel Functions
2 Band EQ
Maximum Output Level (1m; on axis)
120 dB SPL *1
Construction
Amplifier Class
Class-D
Cabinet Material
Plastic (PP)
Shipping
Weight
11.5 lbs (5.2 kg), without AC adapter
General
Type
2-way Bi-amp Powered Speaker with mixer
Mixing Channels
>3
Frequency Range (-10dB)
70 Hz – 20 kHz
LF
6.5" Cone, 1.7" voice coil
HF
1" throat compression driver, 1.4" voice coil
Power Rating (Dynamic)
100 W (LF: 93 W, HF: 7 W)
Cooling
Natural convection (no fan)
Handle
Bottom x1 (Rotatable)
Flying and Mounting Hardware
1 × 3/8", depth 12 mm (center of handle)
Inputs
INPUT 1
Combo (mic/line), INPUT 2: Combo (mic/line), INPUT 3: Stereo Mini x1 (line)
IR
Coverage Area
H90° x V90°
