Specifications
Dimensions
Cutout Size
Ø7.31"
Dimensions
8.9" diameter x 7.7" depth
Audio
Speaker Type
full-range, bass-reflex
Sensitivity (1W; 1m on axis)
87dB SPL (Half-space:2π)
Connectivity
I/O Connectors
1 x Euroblock (4P) : (Input: + / -, Loop Thru: + / -)
Shipping
Weight
5.7 pounds
General
Frequency Range (-10dB)
80Hz - 20,000Hz (Half-space:2π)
Nominal Coverage
130° conical (Half-space:2π)
Components (LF-HF)
4" full range
Noise
30W
PGM
60W
Peak
120W
Nominal Impedance
8Ω
100V
30W (330Ω), 15W (670Ω), 7.5W (1.3kΩ)
70V
30W (170Ω), 15W (330Ω), 7.5W (670Ω), 3.8W (1.3kΩ)
Peak (calculated)
108dB SPL (1m, Calculated based on power rating and sensitivity, exclusive of power compression)
Certificate
UL1480, UL2043, NFPA70, CE, EAC, RoHS
Required Ceiling Board Thickness
5mm - 35mm
