Specifications
Dimensions
Dimensions (WxHxD)
10.2x19.7x15.3” (260x500x389mm)*5
Weight
Net Weight
36.4lbs (16.5kg)*5
Electrical
Satellite Impedance
8Ω load per satellite output recommended *2
Audio
Speaker Type
Bass-reflex type Subwoofer
Sensitivity (1W; 1m on axis)
96dB SPL *3
Connectivity
I/O Connectors
Input: 1x Euroblock (4P)(CH1: + / -, CH2: + / -), Satellite Output: 1x Euroblock (4P)(ST 1: + / -, ST 2: + / -)
Construction
Cabinet Material
MDF
Finish
VXS10S: Black (approximate value:Munsell N3), VXS10SW: White (approximate value:Munsell 3.5PB9.0/1)
Included Items
Components
LF: 10" Dual Voice Coil
Identifiers
Packaging
Packaged each
General
Frequency Range (-10dB)
45Hz - 250Hz
NOISE
100W + 100W
PGM
200W + 200W
Nominal Impedance
8Ω + 8Ω
Peak (Calculated)
125dB SPL *4
Shape
Rectangular
Certificate
CE, EAC, RoHS
Protection Circuit (Load protection)
Full-range power limiting for protecting network and transducers
Options
UB-DXR8: U-Bracket
