Specifications
Dimensions
Dimensions (DWH Xbackw, inches)
14.5 x20.5 x16
Dimensions (DWH Xbackw, cm)
36.8 x 52.1 x 40.6
Weight
Weight (lbs/kg)
52 / 23.6
Electrical
LF Impedance (Ohms)
2 Ohm Load
Power Consumption (typ/max)
135 VA / 225 VA
Audio
Max SPL (dB)
128dB Peak (125dB Continuous)
Frequency Response (Hz +/- 3dB)
75Hz-20K
Input Sensitivity (Vrms Sine)
Line in 1.4 at center, 0.35 at max
Connectivity
Power Cable
Removable Locking IEC Input and Loop Thru Output
Inputs
1 Combijack (XLR / 1/4-inch)
Construction
Cooling Scheme
Convection
Enclosure Materials
Injection Molded ABS
Baffle Material
Injection Molded ABS
Covering / Finish
Paint
Controls
Power Switch
Yes
LED Indicators
Power, Limit, Clip
General
Active Or Passive
Active
Power Rating (Watts)
700 (1200 Watts Peak)
Biampable
Biamp
Crossover Frequency (Hz)
1.2K
Driver Configuration
2x1", 4x6"
HF Driver(s)
2x1-inch Ceramic w/ 1.75-inch VoiceCoil
HF Power Rating (Watts)
75 Watts (200 Watts Peak)
HF Dispersion (°H X °V)
110x15
HF Protection
Peak and Average Limiting
LF Driver(s)
4x6-inch neo with 45mm VC
LF Power Rating(Watts)
675 Watts Program (1000 Watts Peak)
LF Protection
Excursion, RMS
HF Power Amplifier (Watts)
75W
HF Amplifier Type
2-Tier Class H
LF Power Amplifier (Watts)
625W
LF Amplifier Type
Class D
Level Controls
Volume
EQ Controls
HF Boost switch, Fullrange/Sub switch
Limiter
Peak and Average limiting on horn and woofer
Optional Flying Hardware
1 x PSA1RIGKIT per cabinet, 1 x PSA1FRAME1 per hung
Optional Covering / Finishes
Optional Colors available
