- Recording mediaSD cards, SDHC cards, SDXC cards (that conform to standards)
- Inputs 1-6Connectors XLR jack (pin 2 hot)
- EIN−127 dBu or less (A-weighted, +75 dB input gain, 150 Ω input)
- Input (mic)
- Input gain: +12 dB to +75 dB
- Input impedance: 3 kΩ or more
- Max input level: +4dBu
- Input (line)
- Input gain: −8 dB to +55 dB
- Input impedance: 5 kΩ or more
- Max input level: +24 dBu
- Line output
- Connectors: 3.5 mm stereo mini unbalanced output
- Output impedance: 100 Ω or less
- Reference output level: –10 dBV, 1 kHz, 10 kΩ load
- Max output level: +10 dBV, 1 kHz, 10 kΩ load
- D/A dynamic range: 95 dB typ (−60dBFS input, A-weighted)
- Headphone output
- Connector: 3.5 mm stereo mini unbalanced output
- Output impedance: 3.5 mm stereo mini unbalanced output
- Max output level: 100 mW + 100 mW (32Ω load)
- D/A dynamic range: 108 dB typ (−60dBFS input, A-weighted)
- Timecode connectors3.5 mm stereo mini (Tip: IN, Ring: OUT)
- Display1.54" full-color LCD (240×240)
- Dimensions (WxDxH)3.94x4.72x2.48"
- Weight1.16 lbs
