- Input channels6 mono mic inputs, 1 stereo smartphone input
- Output channels2 (6 headphones and L/R speaker outputs)
- Mic
- Connector: XLR jacks (2:HOT)
- Input gain: 0 to 70 dB
- Input impedance: 3 kΩ (XLR)
- Max input level: +5 dBu (@0dBFS)
- Smartphone connection jack
- Type: TRRS mini jack (4 contacts, TIP: L, RING 1: R, RING 2: GND, SLEEVE: MIC)
- Input impedance: 3 kΩ
- Max input level: +2.5dBu
- Headphones
- Connector: 3.5mm stereo mini
- Max output level: 20 mW + 20 mW @32 Ω
- Output impedance: 27Ω
- Speaker output
- Type: TRS jacks (balanced)
- Max output level: +5.5dBu
- Output impedance: 320 Ω
- Recording media
- 4-32 GB cards compatible with the SDHC specification (class 10 or higher)
- 64-512 GB cards compatible with the SDXC specification (class 10 or higher)
- Audio interface44.1kHz, 16-bit, 6 in / 2 out
- Frequency response-1.0 dB: 20 Hz ~ 20 kHz @44.1 kHz
- EIN-124 dBu (IHF-A) @+70 dB, 150 Ω input
- Display4.3" (480x272) full-color touchscreen LCD
- Power supply4 AA batteries OR AC adapter (Zoom AD-14) OR USB bus power
- Dimensions (WxDxH)11.61" x 9.76" x 2.4"
- Weight3.15 pounds (1.43 kg)
