RCF NX-L44A-MK2 Column Array Powered Speaker

The RCF NXL 44-A features a 2-channel 1,400W amp powering three 10” neodymium woofers and a 1.4” driver with 3” voice coil on an asymmetrical waveguide.

NXL 44-A is a line array column speaker featuring a two-channel 1,400 watt amplifier powering three 10” neodymium woofers and a 1.4” driver with 3“ voice coil on an asymmetrical waveguide. The horn’s design delivers accurate sound to the coverage area without tilting the enclosure. The speaker delivers an extended frequency range down to 45 Hz, used alone or coupled with subwoofers for medium-sized concerts and DJ sets. Precision controlled by an on-board DSP, the NXL 44-A is ideal for professional live sound reinforcement with sleek design, incredible power, and sound detail. A complete set of rigging accessories allows for simple flying and stacking.

Please Note: In order to securely pole-mount the NX-L44A, the K&M 21441 Professional Adapter Sleeve for 35mm Pole is required.

RCF NXL 44-A MK2 Features

• 1,400 Watt Class D bi-amplification
• 90° x 30° constant directivity waveguide, tilted (+5°, -25°)
• 3 x 10" neodymium woofers
• 1.4" compression neodymium driver, 3" voice coil
• DSP processing with optimized phase response
• Easy to fly and install with built-in rigging points and pole mount socket
• Thermal and RMS protections
• Soft Limiter
• Controls for volume, EQ shape, mic/line
• Please Note: In order to securely pole-mount the NX-L44A, the K&M 21441 Professional Adapter Sleeve for 35mm Pole is required.

• NXL 44-A MK2 2-way column array powered speaker1

• Frequency response 45 - 20,000Hz
• Max SPL (@ 1M) 134dB
• Horizontal coverage angle 90°
• Vertical coverage angle 30°
• Compression driver 1 x 1.4" neo, 3" v.c
• Woofer 3 x 10" neo, 2.5" v.c
• Input signal bal/unbal
• Input connectors XLR, jack
• Output connectors XLR
• Input sensitivity -2dBu / +4dBu
• Crossover frequencies 800Hz
• Total power 1400W peak, 700W RMS
• High frequencies 400W peak, 200W RMS
• Low frequencies 1000W peak, 500W RMS
• Connections Powercon IN/OUT
• Cabinet/case material Baltic birch plywood
• Grille steel
• Hardware 4x M8, 4x quick lock, 2x pole mount
• Handles 4 side
• Pole mount/cap yes
• Dimensions (HxWxD) 47.17x11.93x15.83"
• Weight 76.06 pounds (34.5 kg)

More about RCF's NX Column Speakers

RCF's NX Series of are comprised of masterfully engineered wooden speakers with remarkable audio performance and extended versatility for professional audio applications.
