• Ashly TRA-2075 Power Amplifier
1 1

Ashly TRA-2075 Power Amplifier

Ashly TRA-2075 Power Amplifier

Soundpro Item: 41419 | Part Number: TRA-2075

$1,189.00
$1,486.00 $1,189.00
Your Price Sold out
MSRP: $1,486.00 | MAP: $1,189.00
  • Convection cooling
  • 2RU configuration
  • Extremely low ambient noise
  • Internally-mounted constant voltage transformers
  • Extensive protection circuitry including output overcurrent protection, DC output protection, main supply rail overvoltage protection, in-rush limiting and mains fuse
  • 6-step signal level and clip LEDs
  • Rear panel level attenuators for each channel
  • Rear panel Gain Switch: +36 dB or +26dB input sensitivity
  • Euroblock inputs/outputs
  • Selectable input sensitivity (voltage gain)
  • Remote stand-by control
  • Adjustable turn-on delay up to eight seconds
  • Safety/Compliance: TUV, CE, FCC, RoHS
  • 5-Year Warranty
Log in or register for YOUR best price

The TRA-2075 is 2 channels with 75 watts per channel.

These 2 rack space amplifiers utilize Ashly's advanced, efficient amplifiers perfect for low impedance, 25V, 70V or 100V installations with modest power requirements. They also feature a switch-mode power supply with Class-D circuitry, providing an extremely power-efficient solution. All TRA Series amplifiers are convection-cooled, so there’s little maintenance after the installation, and no annoying fan noise.

A 6-step LED meter for each channel lets you monitor all levels. TRA amplifiers can drive 4 or 8 Ohm loads and 25V or 70V and 100V Constant Voltage lines simultaneously. Output transformers are internally mounted. All TRA audio controls are on the rear panel.

View full details

Specifications

  • Frequency Response (8Ω)20Hz–20kHz, ± 1.0 dB, -3dBu @ 80Hz Due to internal HPF
  • Distortion (SMPTE, typical)< 0.5%–8 Ohm load, 10dB below rated power
  • Distortion (THD-N, typical)< 0.5%–8 Ohm load, 10dB below rated power, 20Hz–20kHz
  • Damping Factor (8Ω load, <1kHz)> 200 into 8 Ohms
  • Input Impedance20k ohms, balanced
  • Input Sensitivity1dBu (75W), 4dBu (150W)
  • Gain26dBu, 36dBu, selectable
  • Max. Input Level+21dBu
  • HPF80Hz 2nd Order, defeatable
  • Coolingconvection
  • Output CircuitryClass D
  • Amplifier/Load ProtectionOutput Overcurent, DC Output, Main Supply Rail Overvoltage, Chassis Temperature, Inrush Limiting, Mains Fuse
  • Environmental40°-120°F (4-49°C) noncondensing
  • Front Panel
    • Controls: AC power switch
    • Indicators (LED color)
      • Power (blue)
      • Standby (yellow)
      • Protect (red)
      • Clip (red)
      • Signal Level -24dB, -18dB, -12dB, -6dB (green)
      • Signal level -3dB (yellow)
      • Clip (red)
  • Rear Panel
    • Controls: Input Attenuators, Gain / Sensitivity: +26dB, +36dB, Remote Stand-by, Delay
    • Connectors (each channel)
      • Input: 3-pin Euroblock
      • Output: Euroblock
    • Cordset: 3-prong IEC
  • Channels2
  • Max Output Power
    • Per Channel, 80Hz - 20kHz, 1% THD, All Channels Driven
    • 4Ω: 75W
    • 8Ω: 40W
  • Constant Voltage Options
    • 80Hz - 20kHz, 1% THD, All Channels Driven
    • 25V (per channel): 75W
    • 70V (per channel): 75W
    • 100V (per channel): 75W
  • Line Current Draw
    • All Channels Driven @ 4Ω
    • Standby Mode: 37mA
    • No Signal (idle): 320mA
    • Typical (1/8 power pink noise): 0.70A
    • Max (1/3 power sine wave): 1.23A
  • Thermal Dissipation
    • BTU/hr, All Channels Driven @ 4Ω
    • Standby Mode: 13
    • No Signal: 61
    • Typical (1/8 power pink noise): 73
    • Max (1/3 power sine wave): 85
  • Signal to Noise
    • 20Hz - 20kHz, Unweighted: >100dB
  • Power Req.120VAC, 240VAC ±10%, 50/60Hz (factory set)
  • Dimensions (WxHxD)19" x 3.5" x 12"
  • Weight19.9 pounds
