Specifications
Video
HDMI Specification
HDMI 2.0, HDCP 2.2
Maximum TMDS Clock
600 MHz
Maximum Resolution
4096 x 2160 DCI @ 60 Hz
4K/UHD Support
3840 x 2160 @ 60 Hz
Chroma Subsampling
4:4:4, 4:2:2, 4:2:0
Color Depth
8-bit, 10-bit, 12-bit
HDR Support
HDR10, Dolby Vision @ 60 Hz, Hybrid Log-Gamma
Audio
Pass-Through Formats
PCM, Dolby Digital, Dolby Digital Plus, Dolby TrueHD, Dolby Atmos, DTS Digital Surround, DTS-HD Master Audio, DTS:X
Sample Rates Supported
32 kHz, 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz
Bit Depth
up to 24-bit
Connectivity
HDMI Input
1 x Type A 19-pin female
HDMI Outputs
8 x Type A 19-pin female
Analog Audio Output
1 x captive screw 5-pin
S/PDIF Output
1 x RCA female
Firmware Port
1 x Mini-USB Type-A
Power Input
1 x locking connector female
Power Backup
1 x locking connector female
Performance
Cable Distance @ 4K
up to 15 feet
Cable Distance @ 1080p
up to 30 feet
Power
Input Voltage
AC 100–240V 50/60 Hz
Output Voltage
DC 5V
Power Consumption
6.75 W
Dimensions
Height
1.73"
Width
17.07"
Depth
10.03"
Weight
Product Weight
6.13 lbs
Shipping Weight
8.00 lbs
Shipping
Shipping Height
3"
Shipping Width
19"
Shipping Depth
12"
Environmental
Operating Temperature
32°F to 122°F
Storage Temperature
-4°F to 140°F
Operating Humidity
20 to 90% non-condensing
Certifications
Safety Certifications
CE, FCC, cULus, RoHS
