Audix ADS48 Combines4;2Channel Systems;8Channels W/1 Set Of Antennas;1 Power Supply

Audix ADS48 Combines4;2Channel Systems;8Channels W/1 Set Of Antennas;1 Power Supply

SoundPro Item: 73511 | Part Number: ADS48

$699.00
$839.00 $699.00
Your Price Sold out
| MAP: $699.00

Usually ships in 5-7 business days

  • Minimum Frequency: 470 MHz
  • Maximum Frequency: 900 MHz
  • BNC In: Yes
  • BNC Out: Yes
  • Number of BNC Inputs: 2
  • Number of BNC Outputs: 8
  • Input Voltage: 120 V AC
  • Input Voltage: 230 V AC
  • Height: 1.8"
  • Width: 18.9"
  • Depth: 9.8"
  • Weight (Approximate): 4.74 lb
  • Country of Origin: China
  • Limited Warranty: 1 Year
Log in or register for YOUR best price

Antenna distribution system - combines 4 - two channel systems (8 channels) with one set of antennas and one power supply.The Audix ADS48 is a wide range UHF antenna distribution system that combines up to four wireless systems to be able to run off a single pair of antennas and power supply. The ADS48 has an internal switching power supply which eliminates the need for the individual DC power supplies normally needed for each receiver. RF signals are internally amplified in order to compensate for any loss that may result from splitting the signal.When used in conjunction with the AP42 or AP62 two channel systems, the ADS48 is able to run 8 channels of wireless on a single pair of antennas and power supply take up only 5 rack spaces.

View full details

Specifications

'General Information
Manufacturer
Audix Microphones
Manufacturer Part Number
ADS48
Brand Name
Audix
Product Model
ADS48
Product Name
ADS48 UHF Antenna Distribution System
Packaged Quantity
1
Product Type
Audio Distribution Amplifier
Technical Information
Minimum Frequency
470 MHz
Maximum Frequency
900 MHz
Interfaces/Ports
BNC In
Yes
BNC Out
Yes
Number of BNC Inputs
2
Number of BNC Outputs
8
Power Description
Input Voltage
120 V AC
230 V AC
Miscellaneous
Package Contents
ADS48 UHF Antenna Distribution System 2 x Antennas 1 x IEC power cable 4 x Power Jumper Cables to provide power to individual receivers 8 x BNC-to-BNC Coaxial Cables for pass through connection for up to 4 additional receivers (single or dual) 2 x Coaxial cables for front mounting antennas -
Country of Origin
China
Warranty
Limited Warranty
1 Year
