Audix M40 Miniature Condenser Ceiling Microphone
Audix M40 Miniature Condenser Ceiling Microphone
SoundPro Item: 73330 | Part Number: M40W12
Usually ships in 5-7 business days
- Optimized for voice recognition
- Immunity from RF interference
- Point and shoot directivity
- Integrated preamp circuitry
- 12mm gold vapor diaphragm
- Extremely low noise, high sensitivity
- 3 Year Warranty
The M40 is a miniaturized condenser microphone with a fully integrated preamp designed with very high sensitivity for distance miking. The primary applications for the ceiling-mounted M40 include Video & Teleconferencing (VTC), distance learning, hospital rooms, surveillance, and ambient room miking.
The M40 ceiling microphone has complete immunity from RF interference caused by cell phones and GSM devices. The M40, which comes with a cardioid capsule, is also available with hypercardioid or shotgun capsules, allowing for the microphone to be used in a wide variety of applications.
The M40 installed ceiling microphone is easy to install requiring only that a 5/8 inch hole be drilled in the ceiling with no additional tools required. The cable assembly is equipped with a terminal block connector. For installations where a plenum-rated cable is to be used, a UL-rated metal plenum junction box is available.
M40 Models
- M40W12: cardioid capsule, 12" gooseneck
- M40W6: cardioid capsule, 6" gooseneck
- M40W12HC: hypercardioid capsule, 12" gooseneck
- M40W6HC: hypercardioid capsule, 6" gooseneck
- M40W12S: shotgun capsule, 12" gooseneck
- M40W6S: shotgun capsule, 6" gooseneck
- Transducer TypeCondenser
- Polar PatternsCardioid (M40W12, M40W6), Hypercardioid (M40W12HC, M40W6HC), Shotgun (M40W12S, M40W6S)
- Frequency Response60 Hz - 10 kHz
- Output Impedance150 Ω
- Sensitivity37 mV / Pa @ 1k
- Equivalent Noise Level22 dB (A-weighted)
- Max SPL≥130 dB (@ .5% THD)
- Dynamic Range108 dB
- Power Requirements18 - 52 V phantom
- Connectorterminal block connector
- Constructioncopper and steel powder coat
- Length2.1"
- Weight0.7 oz (20 g)
