Biamp Parlé TCM-X Beamtracking Ceiling Microphone | White

Biamp Parlé TCM-X Beamtracking Ceiling Microphone | White

SoundPro Item: 43852 | Part Number: 920-00498-20000

$2,436.75
$2,565.00 $2,436.75
Your Price Sold out
MSRP: $2,565.00 | MAP: $2,436.75

Usually ships in 5-7 business days

  • 16-Element Digital Array Delivers Professional Voice Capture With Four Independent Beamformed Zones
  • Single CAT5 Installation Reduces Labor And Cable Management Complexity In Ceiling Plenum Runs
  • Onboard Network Box DSP Processing Consumes Only One AEC Channel Per Microphone Within Tesira Systems
  • Expansion Port Supports Addition Of TCM-XEX Microphone For Larger Rooms Without Additional Network Boxes
  • LED Mute Indicator Provides Real-Time Visual Confirmation Of Microphone Status To Meeting Participants
  • Microsoft Teams And Zoom Certification Ensures Seamless Integration With Enterprise UC Platforms
  • UL 2043 Plenum Rating And TAA Compliance Meet Government And Education Installation Standards
Log in or register for YOUR best price

The Parlé TCM-X addresses the need for high-quality voice capture in modern conferencing environments where aesthetic integration is as important as performance. Its 16-element digital array uses four independent 90-degree zones to automatically locate and follow active speakers without manual tuning, delivering natural conversation flow in huddle rooms, boardrooms, and collaborative workspaces. Integrators benefit from simplified deployment: a single CAT5 connection between microphone and network box reduces both material cost and labor hours, while consuming just one acoustic echo cancellation channel within Tesira DSP systems.

Designed for rooms with ceiling heights up to 10 feet, the TCM-X supports expansion through an onboard RJ-45 port that accommodates a TCM-XEX microphone when broader pickup is required. Built-in LED indicators provide instant mute status visibility to participants, and Microsoft Teams plus Zoom certification ensures compatibility with enterprise unified communication platforms. UL 2043 plenum rating and TAA compliance make this solution suitable for government and education installations with strict regulatory requirements.

View full details

Specifications

Certifications
TAA Compliant
Yes
Microsoft Teams Certified
Yes
Zoom Certified
Yes
UL 2043 Air Handling
Yes
CE Marked
Yes
UL and C-UL Listed
Yes
RoHS Directive
Yes
FCC Part 15B
Yes
Dimensions
Diameter
5.9"
Height
1.2"
Width
6.8"
Depth
5.2"
Weight
Weight
1.4 lbs
Audio
Microphone Elements
16-Element Digital Array
Polar Pattern
Active Beamformed
Frequency Response
150 Hz - 16 kHz (± 3dB)
SNR
> 76dB (at 1kHz, 94dBSPL A-Weighted)
Dynamic Range
92dB A-Weighted (THD+N < 1%)
Maximum SPL
109dB (at < 1% THD)
Coverage Zones
Four 90-degree zones
Connectivity
Network Connections
Three RJ-45 (network box)
Microphone Cable Length
6.6' (2 meters)
Max Cable Distance Switch to Network Box
330' (100 meters)
Max Cable Distance Network Box to TCM-XEX
33' (10 meters)
Power
Power Requirement
PoE (IEEE 802.3at Class 3, 15.4W)
Controls
Front Panel Indicators
Mute LED (Green/Red), Power LED (Green/Yellow/Red)
Environmental
Operating Temperature
32 - 104° F (0 - 40° C)
Humidity
0-95% relative humidity (non-condensing)
Altitude
0-10,000 ft (0-3000m) MSL
Included Items
Optional Accessories
Seismic Cable Adapter, TB-1 Tile bridge, TCM-X Installation Tool, TCM-X-DK Plenum attachment, TCM-X-FM Flush Mount Kit, Plenum Box 12x12, C5E-10-P, C5E-25-P
