- Frequency Range (-10 dB)70 - 17,000 Hz
- Coverage, Horizontal130°
- Calculated Maximum SPL @ 1 m105 dB
- Nominal Impedance8 Ω (transformer bypass)
- Power Handling, long-term continuous40 W
- Power Handling, Peak160 W
- Sensitivity (SPL/1 W at 1 m)89 dB
- Transformer Taps, 100V5, 10, 20, 40 W, bypass
- Transformer Taps, 70V2.5 W, 5 W, 10 W, 20 W, 40 W, bypass
- Coverage, Vertical125°
- Product Dimensions10.0 in x 6.7 in x 6.8 in (254 mm x 171 mm x 174 mm), loudspeaker / 10.7 in x 6.7 in x 7.7 in (273 mm x 171 mm x 196 mm), loudspeaker with bracket
- Operating Temperature Range-25 °C to 70 °C (-13 °F to 158 °F)
- Ingress ProtectionIP55
