Bose AudioPack Pro S4 Background Music and Paging System

Bose AudioPack Pro S4 Background Music and Paging System

SoundPro Item: 147728 | Part Number: 892255-1110

$999.00
$999.00 $999.00
Your Price Sold out
MSRP: $999.00 | MAP: $999.00

Usually ships in 5-7 business days

  • EN 54-24 Certification Ensures Compliance For Life Safety Paging Applications
  • Opti-Voice EQ And Dynamic Low-End Compensation Maintain Clarity Across Varying Program Levels
  • Integrated DSP With FreeSpace Loudspeaker Presets Eliminates External Processing Hardware
  • Dual-Channel Architecture With Page Priority Supports Independent Source Zones
  • Plenum-Rated Loudspeaker Construction Meets Commercial Building Code Requirements
  • Removable Rotatable Logos And Powder-Coated Grilles Blend Into Customer-Facing Environments
Log in or register for YOUR best price

AudioPack Pro delivers turnkey background music and paging infrastructure for commercial environments where consistent sound quality and ease of installation determine project success. The system pairs a FreeSpace IZA 190-HZ integrated zone amplifier with FreeSpace FS in-ceiling transducers, pre-matched for tonal consistency and reliable voice intelligibility across retail, hospitality, and corporate installations.

Class D amplification provides 90 watts at 70V or 100V, with dual channels supporting independent source routing and page priority. Built-in DSP presets align amplifier response to FreeSpace loudspeaker models, while Opti-Voice EQ optimizes paging clarity without external processing. Front-panel controls manage input selection, tone shaping, and master level; rear DIP switches configure amplifier mode and loudspeaker equalization for specific transducer models.

FreeSpace FS loudspeakers feature 2.25-inch woofers in engineered-plastic baffles with integrated steel backcans, designed for plenum-rated ceiling installations. Rotatable, removable logos and perforated steel grilles maintain visual discretion in customer-facing spaces. The system scales to business requirements with available package configurations and supports expansion when additional coverage zones are required.

View full details

Specifications

Compliance
EN 54-24 Certified
Yes
Amplification
Number of Channels
2
Power Class
Class D
Rated Power, Symmetrical
90 W at 70V, 100V
Frequency Response
60 Hz – 20 kHz (+0 dB/-3 dB) at 1 W, 1 kHz reference
THD+N
≤ 1% at full rated power
Dynamic Range
88 dB
Channel Separation (Crosstalk)
≤ -60 dBV below rated power, 1 kHz
Audio Inputs
Input Channels
2 unbalanced line, 1 balanced mic/line, 1 balanced mic (page), 1 unbalanced line (auxiliary)
Connectors
RCA stereo pair, XLR-1/4" combo, 4-pin Euroblock, 1/8" TRS
Input Impedance
20 kΩ line / 2 kΩ mic/line / 2 kΩ page / 20 kΩ auxiliary
Input Range
-10 dBV to +10 dBV line / -60 dBV to +10 dBV mic/line / -60 dBV to +10 dBV page / 0 dBV to +10 dBV auxiliary
Maximum Input Level
+10 dBV
Nominal Input Level
0 dBV line / -40 dBV mic/line / -40 dBV page / 0 dBV auxiliary
Adjustment Range
-20 dB to +20 dB line / 0 dB to +50 dB mic/line / 0 dB to +50 dB page / fixed auxiliary
Audio Outputs
Channels
1
Connectors
3-pin inverted Euroblock, RCA stereo pair
Output Impedance
N/A amplifier / 400 Ω auxiliary
DSP
A/D and D/A Converters
48 kHz / 24-bit
Audio Latency
10.4 ms (analog input to analog output)
Processing Functions
Loudspeaker EQ, Opti-Voice EQ (paging), Dynamic EQ (low-end compensation)
Presets
High-pass filter, Bose Professional loudspeaker presets (FreeSpace FS2C/FS2P/FS2SE/FS4CE/FS4SE)
Electrical
Mains Voltage
100–240 VAC (±10%), 50/60 Hz
Mains Connector
IEC C14 inlet
AC Power Consumption
15 W idle, 200 W maximum
Current Draw, Inrush
7.6 A at 120 VAC, 60 Hz / 13.9 A at 230 VAC, 50 Hz
Protections
High temperature, short circuit
Controls
Front Panel Controls
Power switch, input selection switch, treble knob, bass knob, mic/line gain knob, master level knob
Rear Panel Controls
Amplifier Mode DIP switch, Loudspeaker EQ preset selector, Input Gain (A/B/Page mic), Output trim
LED Status Indicators
Power LED, input clip LED
Performance
Frequency Range (-10 dB)
83 – 19,000 Hz
Sensitivity (SPL/1 W at 1 m)
86 dB
Calculated Maximum SPL @ 1 m
98 dB
Coverage, Horizontal
150°
Coverage, Vertical
150°
Nominal Impedance
16 Ω (transformer bypass)
Power Handling, Long-Term Continuous
16 W
Power Handling, Peak
64 W
Transformer Taps, 70V
1 W, 2 W, 4 W, 8 W, 16 W, bypass
Transformer Taps, 100V
2 W, 4 W, 8 W, 16 W, bypass
Transducers
Low-Frequency
1 × 2.25" woofer
Driver Protection
Recommended high-pass protection 85 Hz with minimum 24-dB/octave filter
Physical
Enclosure Material
Engineered-plastics front baffle with integrated steel-formed backcan
Grille
Perforated steel, powder-coated finish
Colors
White (similar to RAL 9003)
Logo
Rotatable, removable
Suspension/Mounting
2 mounting arms, 1 safety cable attachment point
Ceiling Cutout
6.3"
Rack Spaces
1 RU high, half rack wide
Cooling System
Natural convection
Environmental
Operating Temperature Range
0 °C to 50 °C (32 °F to 122 °F)
Environmental
Indoor only, suitable for use in plenum locations (loudspeakers only)
Weight
Net Weight Loudspeaker
3.6 lbs (single with grille)
Net Weight Amplifier
7.0 lbs
Identifiers
Warranty Period
5 years
