Specifications
AMPLIFICATION
Maximum Peak Power, Symmetrical
15 W
Rated Power, Symmetrical
15 W, < 0.3% distortion over frequency range
COMPLIANCE
Safety
IEC/UL/EN 60065:2014/A11:2017, IEC/UL/EN 62368-1:2014/A11:2017
Environmental
RoHS
EMC
FCC Part 15B Class B, ICES-003 Class B, CISPR 13, EN55032 Class B, EN55035, EN61000-3-2, EN61000-3-3, BSMI CNS13439
CAMERA AND VIDEO
Focus Distance
0.5 m (1.6 ft) to ∞
Field of View (FOV)
123° diagonal x 115° horizontal x 81° vertical
Image Sensor
8 MP
Lens
Up to 5x digital zoom
Positioning
2 autoframing modes (Group or Individual), manual pan-tilt-zoom (PTZ) with configurable presets
Processing
Automatic white balance, automatic brightness, digital noise reduction
Supported Video Resolutions
UHD 2160p (4K), 1080p, 720p, 960x480, 848x480, 640x480, 640x360, 432x240 (30 fps)
USB Device Video Class (UVC)
v1.1
Video Encoding
H.264, M-JPEG
COMMUNICATION PORTS
Bluetooth
Bluetooth 4.2 HSP, A2DP, AVRCP, Bluetooth Low Energy
Network
Wi-Fi 802.11ac (wireless)
ELECTRICAL
AC Power Connector
External power supply with local power cord (included)
AC Power Input
110-240 VAC, 50/60 Hz, 1.5 A maximum
GENERAL
System Requirements
Windows 8.1 or 10 / macOS 10.10 or later / Chrome OS (Google Chromebook)
Software Applications
Videobar Configuration (Windows, macOS, web browser), Videobar Administration (Windows), Videobar Mobile (Android, iOS)
Computer Interface Connection
USB Type-C (USB 3.0 UAC, UVC, HID)
MICROPHONE
Microphone Type, Quantity and Size
4 microphones
Pickup Range
4.0 m (13.1 ft)
Technology
Static and adaptive dynamic beam-forming, 3 exclusion zones, acoustic echo cancellation (AEC), digital noise suppression
INDICATORS AND CONTROLS
LED Status Indicators
(1) LED light bar, (1) status LED, (1) Bluetooth LED
PHYSICAL
Colors
Black
Suspension/Mounting
Tabletop stand, wall-mount bracket, display mounting kit (optional), mud ring (optional)
Operating Temperature Range
0 °C to 40 °C (32 °F to 104 °F), 90% non-condensing humidity
Product Dimensions (HxWxD)
10.5 in x 1.9 in x 3.4 in (267 mm x 48 mm x 87 mm)
Net Weight
2.1 lb (1.0 kg)
Storage Temperature
-40 °C to 70 °C (-40 °F to 158 °F), 93% relative humidity
Shipping Weight
5.1 lb (2.3 kg)
PERFORMANCE
Calculated Maximum SPL @ 1 m
86 dB (IEC 60268-5, mono input, wall-mounted)
