- DMX Channels8 or 14
- DMX Connectors3-pin XLR
- Pan and Tilt540° / 234°
- Pan and Tilt Ranges540°, 360°, 180° pan/270°, 180°, 90° tilt
- Colors8 + white, split colors, continuous scroll at variable speeds
- Gobos7 + open (6 metal + 1 glass), rotating, interchangeable, slot-n-lock, continuous scroll at variable
- Light Source1 LED (cool white) 75W, (3.3 A), 50,000 hours life expectancy
- Strobe Rate0 to 20 Hz
- Power Linking7 units @ 120V; 11 units @ 230V
- Input Voltage100 to 240 VAC, 50/60 Hz (auto-ranging)
- Power and Current
- 124W, 1.8 A @ 120V, 60 Hz
- 128W, 1 A @ 230V, 50 Hz
- Gobo Size24 mm outside, 20 mm image, 1.1 mm max thickness
- Prism3-facet round, static
- Zoom Angle (manual)12° to 17°
- Illuminance
- 12°: 17,458 lux @ 2 m
- 17°: 12,848 lux @ 2 m
- Color Temperature15,000K
- Bracket Mounting Hole13mm
- Optional ControllersRFC, RFC-XL
- Dimensions9.1x6.4x13.8"
- Weight12.2 lbs
