- DMX Channels9 or 15
- DMX Connectors3-pin XLR
- Pan and Tilt540° / 270°
- Pan and Tilt Ranges540°, 360°, 180° pan/270°, 180°, 90° tilt
- Colors7 + white, split colors, continuous scroll at variable speeds
- Gobos7 + open (6 metal + 1 glass), rotating, interchangeable, indexing, slot-n-lock, continuous scroll at variable speeds
- Light Source1 LED (cool white) 200W, (16 A), 50,000 hours life expectancy
- Strobe Rate0 to 20 Hz
- Lumens7161
- Power Linking4 units @ 120V; 8 units @ 230V
- Input Voltage100 to 240 VAC, 50/60 Hz (auto-ranging)
- Power and Current
- 354W, 3.1 A @ 120V, 60 Hz
- 337W, 1.6 A @ 230V, 50 Hz
- Gobo Size24 mm outside, 20 mm image, 1.1 mm max thickness
- Prism
- 5-facet linear, bi-directional at variable speeds
- 6-facet round, bi-directional at variable speeds
- Zoom Angle (motorized)10° to 23°
- Illuminance
- 10°: 36,801 lux @ 2 m
- 23°: 21,115 lux @ 2 m
- Color Temperature15,000K
- Optional ControllersRFC, RFC-XL
- Dimensions12.7x8.7x18.3"
- Weight27.2 lbs
