- DMX Channels8, 10 or 14
- DMX Connectors3-pin XLR
- Pan and Tilt540°/240°
- Pan and Tilt Ranges180°, 360°, 540° pan/90°, 180°, 240° tilt.
- Colors8 + open, split colors, continuous scroll at variable speeds
- Gobos7 + open (6 metal + 1 glass), rotating, interchangeable, slot-n-lock, continuous scroll at variable speeds
- Light Source1 LED (cool white) 70 W, (3.3 A), 50,000 hours life expectancy
- Strobe Rate0 to 20 Hz
- Zoom Angle(manual) 15° to 17°
- Illuminance
- (15°): 10,012 lux @ 2 m
- (17°): 7,792 lux @ 2 m
- Power Linking5 units @ 120 V; 9 units @ 230 V
- Input Voltage
- 100 to 240 VAC
- 50/60 Hz (auto-ranging)
- Power and Current
- 107 W, 1.5 A @ 120 V, 60 Hz
- 105 W, 1 A @ 230 V, 50 Hz
- Gobo Size24 mm outside, 20 mm image, 1.1 mm max thickness
- Weight11.2 lb (5.1 kg)
- Size9.9 x 7.8 x 13.8 in (251 x 199 x 351mm)
- ApprovalsCE, RoHS, UKCA
- Prism 3-facet round static
- Optional Controllers IRC-6
- Color Temperature 15,000 K
- Bracket Mounting Hole 13 mm
