Chauvet DJ SHOCKERPANELFXIP IP66-Rated RGB Strobe Wash Blinder Panel

Chauvet DJ SHOCKERPANELFXIP IP66-Rated RGB Strobe Wash Blinder Panel

SoundPro Item: 206757 | Part Number: SHOCKERPANELFXIP

$549.99
$733.32 $549.99
Your Price Sold out
MSRP: $733.32 | MAP: $549.99

Usually ships in 5-7 business days

  • IP66-Rated Construction With Integrated GORE Valve For Outdoor Festival And Touring Reliability
  • Neutrik TRUE1 Power Connectors Maintain Water Resistance While Simplifying Multi-Fixture Power Distribution
  • Sixteen Controllable Sections Enable Independent Programming Of RGB Color And Cool White Layers
  • Password-Protected Touch Display Provides Secure Access To Built-In Effect Macros And DMX Settings
  • Four DMX Channel Modes Support Flexible Integration From Simple Triggering To Pixel-Level Control
  • Rapid Strobe Rate And Wide Field Angle Create High-Impact Audience Effects For Live Events
Log in or register for YOUR best price

Shocker Panel FX IP delivers the versatility production professionals demand when moving between indoor stages and outdoor festival environments. The fixture combines 480 tri-color LEDs with 32 cool white emitters across 16 independently controllable sections, enabling everything from synchronized strobe effects to layered wash looks without swapping fixtures. The IP66-rated housing and integrated GORE valve prevent moisture and dust intrusion while allowing internal air exchange, ensuring reliable operation in challenging weather conditions.

Touring crews benefit from Neutrik TRUE1 power input and output connections that maintain water resistance while simplifying cable runs across multi-fixture rigs. The touch-sensitive digital display offers password-protected access to built-in effect macros, letting operators trigger complex looks without external control. With power linking capacity for up to 11 units at 230 V and 13,626 lumens of output, this compact panel scales from small club installations to large-scale festival production while fitting easily into the optional CHS-25 VIP gear bag for transport.

Downloads

View full details

Specifications

Performance
Illuminance
1,131 lux @ 2 m
Lumens
13,626
Strobe Rate
0 to 20 Hz
Beam Angle
119°
Field Angle
158°
Light Source
RGB LEDs
480 tri-color, 2 W each, 50,000 hours
Cool White LEDs
32 LEDs, 1.8 W each, 50,000 hours
Control
DMX Channels
8, 18, 34, or 47
DMX Connectors
5-pin XLR
Construction
IP Rating
IP66
Electrical
Input Voltage
100 to 240 VAC, 50/60 Hz (auto-ranging)
Power and Current
238 W, 2 A @ 120 V, 60 Hz / 231 W, 1 A @ 230 V, 50 Hz
Power Linking
6 units @ 120 V; 11 units @ 230 V
Max Output Current
12 A
Cable Length
5 ft (1.5 m)
Environmental
Startup Temperature
-4 °F to 113 °F (-20 °C to 45 °C)
Operating Temperature
-22 °F to 113 °F (-30 °C to 45 °C)
Dimensions
Size
12.9" x 5.1" x 6.8" (330 x 130 x 173 mm)
Weight
Product Weight
10.4 lbs (4.7 kg)
Shipping
Package Weight
27.78 lbs
Package Dimensions
15.35" x 14.17" x 10.24"
Certifications
Approvals
CE, RoHS, MET
Included Items
What's in the Box
Shocker Panel FX IP, Power Cable, Quick Reference Guide
