- Optical
- Light source: 1 LEDs (quad-color RGBW) 60 W, (4 A), 50,000 hours life expectancy
- Beam angle: 4° to 40°
- Field angle: 8° to 55°
- Zoom range: 4° to 55°
- Illuminance
- 4°: 5,370 lux @ 5 m
- 40°: 97 lux @ 5 m
- Selectable PWM: 600 Hz, 1,200 Hz, 2,000 Hz, 2,400 Hz, 6,000 Hz, 18,000 Hz, 25,000 Hz
- Dynamic Effects
- Dimmer: electronic
- Shutter/strobe: electronic
- Zoom: motorized
- Strobe rate: 0 to 25 Hz
- Standalone color mixing: yes
- Color temperature presets: yes
- Dim modes: 5
- Built-in automated programs: yes
- Customizable programs: yes
- Recall custom programs: yes
- Connections
- Power connection: Edison (local) plug to Seetronic Powerkon IP65
- Power input: Seetronic Powerkon IP65
- Power output: Seetronic Powerkon IP65
- Data connectors: 5-pin XLR IP65
- Power cable length: 5 ft (1.5m)
- Control
- Protocol: DMX, RDM
- DMX channels: 9, 12, or 17
- Modes/personalities: 5 personalities (HSIC, SSP, TOUR, TR16, STD.Y)
- Electrical
- Input voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
- Power linking: 24 units @ 120 V; 40 units @ 208 V; 45 units @ 230 V
- Power and current
- 65 W, 0.548 A @ 120 V, 60 Hz
- 62 W, 0.332 A @ 208 V, 60 Hz
- 65 W, 0.297 A @ 230 V, 50 Hz
- Physical
- Housing material: aluminum die-cast
- Accessory holder/gel frame size: 6.25"
- IP rating: IP65, outdoor/wet, with pressure equalizing M12 GORE valve
- Dimensions: 13.62" x 6.93" x 9.53"
- Weight: 11.8 pounds (5.4 kg)
